This chapter describes the configuration rules and restrictions for configuring the Environmental
Monitor Unit (EMU) and Power and Verification Assembly (PVA). When specific rules and
restrictions are not provided, references are given to the proper StorageWorks documentation.
3.1

Configuring the EMU

Configuring the EMU requires connecting to the EMU communications bus and then
using the CLI SET_EMU command to establish the following:
•
Enclosure backplane temperature sensor set points on all enclosures
– SENSOR_1 or SENSOR_1_SETPOINT = DEFAULT
– SENSOR_2 or SENSOR_2_SETPOINT = DEFAULT
•
EMU module internal temperature sensor set point SENSOR_3 or
SENSOR_3_SETPOINT = DEFAULT
•
The blower speed controls of either FANSPEED = HIGH or FANSPEED =
AUTOMATIC
Compaq recommends setting the FANSPEED to AUTOMATIC, unless (1) the ambient
temperature is in excess of 38ºC (100ºF), (2) there is no air conditioning, or both
conditions exists. Should these conditions exist, Compaq recommends setting the FAN
SPEED to HIGH.
For instructions on using these commands, refer to the CLI
Reference Manual .
EK–SMCPR–UG. A01

Configuring the Storage Cabinet

NOTE
387404–001
3
3–1
