5. If performing a cold swap:
a) Plug in the subsystem's power cord, if it is not already plugged in.
b) On all expansion enclosures, turn on all ac input power entry controllers.
c) On the master enclosure, turn on all ac input power entry controllers.
6. Verify that the amber device fault LED is OFF.
When the SCSI bus is active and the disk drive SBB has
power, the green device activity LED is ON, FLASHING, or
OFF. The amber device fault LED is OFF.
5.7.4 Multiple Disk Drive SBB Installation in an UltraSCSI
Enclosure
Use the following steps to install multiple disk drive SBBs:
1. Verify that the disk drive SBB is the correct model, and fill in the bezel label
information for each disk drive SBB.
2. Install all the disk drive SBBs, starting in the lower left corner in shelf 1 (devices 1–
6) and advancing to the right.
EK–SMCPR–UG. A01
Chapter 5. Replacing Components
NOTE
5–17
