UM1590
Table 4.
EXTI line 5
EXTI line 6
EXTI line 7
EXTI line 13
EXTI line 17
2.3.4

Internal memory size

Figure 14. Internal Flash memory organization

2.3.5

External memory organization

The STM32303C-EVAL demonstration is based on an embedded free FAT file system,
FatFs. The file system is needed to read all media information from the on-board MicroSD
card memory. The MicroSD card memory is organized in three subdirectories:
● STFILES: this directory contains all the required demonstration media files (icons).
User files located in this folder cannot be handled by the demo; only default files are
managed.
●
USER: this is a user folder. The user can add his/her own files here to be played inside
the demonstration menus (pictures and waves). This folder is used only by the Image
Viewer and Wave Player submenus. For more details on the various files properties,
please refer to
features.
Caution: The STFILES directory and its internal files are mandatory for demonstration startup. FatFs
is a generic FAT file system module for small embedded systems. The FatFs is written in
compliance with ANSI C and completely separated from the disk I/O layer. For more details,
refer to the following link: http://elm-chan.org/fsw/ff/00index_e.html.
STM32F30x/31x demonstration external interrupts
External interrupts
0x083FFFF
0x0800000
Section 2.4.2: Image Viewer submenu
Doc ID 023892 Rev 1
Key Button (interrupt mode, rising edge)
Joystick DOWN (interrupt mode, falling edge)
Joystick LEFT (interrupt mode, falling edge)
MicroSD Card detect (interrupt mode, rising edge)
KEY Button (interrupt mode, rising edge)
Joystick RIGHT (interrupt mode, falling edge)
Joystick UP((interrupt mode, falling edge)
Joystick SEL (interrupt mode, falling edge)
RTC Alarm (interrupt mode, rising edge)
STM32F303VCT6
Running the demonstration
Used for
and Section 2.4.3: Audio
MS31111V2
21/65
