Running the demonstration
2.1.2

Navigation

The demonstration menu is based on circular navigation, submenu selection, item selection
and back navigation as described in

Figure 10. Navigating in the demonstration menus

You can navigate using the joystick push-buttons located on the evaluation board: RIGHT,
LEFT, SEL, UP and DOWN.
●
The UP, DOWN, RIGHT and LEFT push-buttons are used to perform circular navigation
in the main menu and the current menu items.
●
The SEL push-button selects the current item.
●
The UP and DOWN push-buttons are used for vertical navigation in the submenus.
●
To return to the upper menu, go to the Return line and press SEL.
16/65
Figure
Right
Item 1 Item 2
Left
Left
Right
Left
Item 5 Item 6
Left
Left Right
Item 9 Item 10
Left
Down Down
Item 3
Doc ID 023892 Rev 1
10.
Right
Right
Item 3
Left
Left
Right
Right
Item 7
Left
Left
Right Right
Item 11
Left Left
Down
Item 3.1
Item 3.1.1
Item 3.2
Item 3.1.2
....
....
Item 3.n
Item 3.1.n
Return
Return
UM1590
Item 4
Item 8
Item 12
Right
MS31373V1
