Figure 5. St Logo; Figure 6. Stm32F3 Presentation Slide; Figure 7. Time And Date Configuration - ST STM32303C-EVAL User Manual

Running the demonstration
However, if the icons are correctly loaded in the MicroSD Card memory, the welcome screen
is displayed and the ST logo appears on the LCD (see
Figure 5.
Then, after one second, an STM32F3 presentation slide is displayed on the LCD screen.
Figure 6.
When the board is powered up for the first time, the user is prompted to set the time, year,
month and day. The user may choose to ignore it by pressing any key except for the SEL
push-button to abort the configuration sequence. To set the time and date, the user must
press SEL and follow the setting sequence.
The message shown in
Figure 7.
Note: If the user chooses to configure the time and date, the Time Adjust and Date Adjust menus
are displayed. Otherwise, the main menu is displayed and the user can set the time
14/65
ST logo
STM32F3 presentation slide
Figure 7 appears on the LCD screen.
Time and date configuration
Doc ID 023892 Rev 1
Figure 5).
UM1590
