Control Techniques Unidrive Servo Series Product Data page 8

introduction to macros
Unidrive operation can be simplified by using pre-
configured application macros. These macros are held in
the internal memory of the drive and are user selectable.
Macro summary
Macro Function
0 Default mode
1 Easy mode
2 Motorised potentiometer
3 Preset speeds
4 Torque control
5 PID macro
6 Axis Limit control
7 Hoist control/brake release
8 Digital Lock
When a Macro is not enabled, the drive operates in a default
configuration (EURO USA)
Macro 1 – Easy Mode
Easy mode defines the most commonly used
features with only 10 parameters. These parameters
are numbered 0.01 to 0.10
Drive Connections
Analog Ch 1
0-10v DC
Analog Ch 2
4-20mA Input
Speed Output
Load Output
At Speed Output
Drive Reset Input
Jog Input
Run Forward Input
Run Reverse Input
Analog 1/2 Select Input
External Trip Input
8
Menu 0
Parameter
0.01
0.02
0.03
0.04
0.05
0.06
0.07
0.08
0.09
0.10
Macro 2 – Motorised Potentiometer
motorised potentiometer within the Unidrive by simply
supplying two logic input signals to increase or
decrease the "potentiometer". The output of the
"potentiometer" may be routed to control any of the
drive's non-bit parameters such as speed, torque or
current limit. The function may be configured to reset
upon power cycling or to memorise its value.
Drive Connections
1
2
3
4
5
6
7
8
9
10
11
21
22
23
24
25
26
27
28
29
30
Run Forward
31
& Reverse
Param. Description
1.07 Minimum Speed
1.06 Maximum Speed
2.11 Acceleration time
2.21 Deceleration time
1.14 Reference select
4.07 Current limit
3.10 Proportional gain
3.11 Integral gain
3.12 Derivation gain
3.02 Speed feedback
With this function it is possible to emulate a
Analog Ch 1
0-10v DC
Thermistor
Speed Output
10
Load Output
11
21
22
23
Motorised Pot Up Input
24
Drive Reset Input
25
Motorised Pot Down Up 26
Run Forward Input 27
Run Reverse Input 28
29
An/Mot Pot Select Input
External Trip Input 30
31
x 2
Speed
& Current
x 1
0-10V DC
Motorised pot
Increase &
Thermistor
Decrease
1
2
3
4
5
6
7
8
9
External
Reset Input
