accessories
UNIMOTOR Brushless Servo Motors
Connector Accessories
Control Techniques offers a range of connector
accessories to suit the power and signal connection
requirements of Unimotor UM and SL. Connector
assembly kits, which include the power, signal connectors
and their crimp sockets may be ordered, alternatively,
individual connector assemblies may be ordered.
Power and Signal Connector Packs
Description
Pack Content
17 Way Plug Pack
1 x 17 way signal plug
17 x crimp sockets
1 x 6 way power plug
6 x crimp sockets
5 Way Plug Pack
1 x 5 way solder plug
1 x 6 way power plug
6 x crimp sockets
12 Way Plug Pack
1 x 12 way signal plug
12 x crimp sockets
1 x 6 way power plug
6 x crimp sockets
Individual Connector Packs
Description
6 Way Power
Plug
17 Way Signal
Plug
12 Way Signal
Plug
5 Way Signal
Plug
Use For
Power & signal connection
to UM Motors with
incremental encoder
feedback
Power & signal connection
to SL Motors with CT Coder
and SL electronics
Power & signal connection
to UM Motors with
resolver feedback
Pack Content
Use For
1 x 6 way power plug
Power Connection to
6 x crimp sockets
UM & SL Motors
1 x 17 way signal plug
Signal connection to
17 x crimp sockets
UM Motors with
incremental encoder
feedback
1 x 12 way signal plug
Signal connection to
12 x crimp sockets
UM Motors with
resolver feedback
1 x 5 way solder plug
SL Motors with
CT Coder and SL
electronics
Order Ref.
IM/0012/KI
IM/0024/KI
IM/0011/KI
Order Ref.
IM/0021/KI
IM/0022/KI
IM/0023/KI
7580029
41
