drive overview
Key Features
General Features
Coast & Ramp to Stop modes
8 Preset speeds & Ramps
3 Skip frequencies
S Ramp
Motorised potentiometer
Internal braking transistor as standard
Encoder input as standard
Programmable security code
Bright two line LED display
Advanced Features
Position control
Digital lock
Mains dip ride through
Frequency slaving
Catch a spinning motor
Programmable logic functions
Orientation
Performance Features
336µs speed loop sample time
176µs current loop sample time
16 bit speed loop
12 bit current loop
Dynamic injection/braking
Fast current loop with PI control
Flexibility Features
Speed reference selector
Full I/O programmability
Unisoft
Well structured menu system
Encoder I/P
Programmable logic functions
Configurable menu zero
Programmable thresholds
Resolver feedback
Sin/cos feedback
High speed communications
6
Applications module
High performance module
Ease of Use Features
Macros
Bright two line LED display
Cloning module
Unisoft
Maintenance Features
Clock
Full internal protection & diagnostics
Last ten trips stored
Programmable security code
Common control board
Pluggable terminals
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the Unidrive Servo Series and is the answer not in the manual?
Questions and answers
Need to input parameters into a UNI2402 Unidrive for a Rover 346
Need to input parameters into a UNI2402 Unidrive for a Rover 346 To clarify, it is a Biesse Rover 346... a c&c Machine Thanks
The parameters for a Control Techniques UNI2402 Unidrive Servo can be input using the on-board keypad, a remote keypad, or through UniSoft, a Windows-based configuration software tool. The drive has logically organized menus where parameters can be set.
To input parameters:
1. Use the keypad to navigate through the menus.
2. Select the required function from the logically organized menus.
3. Adjust the parameter values as needed.
4. Save the changes to apply the new settings.
For a Rover 346, specific motor and operational parameters should be set according to the motor’s requirements, such as speed limits, acceleration/deceleration times, braking mode, and PID control settings. If using UniSoft, connect the drive to a PC and configure it through the software interface.
This answer is automatically generated
