connections
Typical power and default signal connections for speed
control in terminal mode
Status relay
Drive normal
Analog frequency/speed
reference 1 (remote)
Connections for
single-ended input
signal
Connections for
differential input
signal
Analog
frequency/speed
reference 2 (local)
SPEED
TORQUE
Analog input 3
Motor thermistor
RESET
JOG SELECT
RUN FORWARD
RUN REVERSE
LOCAL/REMOTE
DRIVE ENABLE
Signal
connector
OV common
OV common
Power
OV common
terminals
+24V
Encoder
OV common
connector
15-way
D-type
REMOTE
LOCAL
OV common
Optional
RFI filter
Thermal
protection
device
Start/
Stop
Reset
Braking resistor
Encoder
Incremental
signal
connections for
all encoders
communication
signal
connectiona for
servo-encoders
17
