User Guide
Mentor II
DC Drives
25A to 1850A
output
Part Number: 0410-0013-12
Issue Number: 12
www.controltechniques.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mentor II and is the answer not in the manual?

Questions and answers

Related Manuals for Control Techniques Mentor II

Summary of Contents for Control Techniques Mentor II

  • Page 1 User Guide Mentor II DC Drives 25A to 1850A output Part Number: 0410-0013-12 Issue Number: 12 www.controltechniques.com...
  • Page 2 This product is supplied with the latest version of user-interface and machine-control software. If this product is to be used with other Control Techniques variable speed drives in an existing system, there may be some differences between their software and the software in this product. These differences may cause a difference in functions.

  • Page 3: Table Of Contents

    Contents Features of Mentor II ......1 Parameter Set ........24 Mentor II parameters ..........1 Adjustment of Parameters ......... 24 Supply phase-sequence ........1 Security .............. 26 Output ..............1 Index of parameters ........... 27 Speed feedback ............1 Mentor parameters that cannot be controlled by Speed reference ...........1...
  • Page 4 The Gro Newtown Powys SY16 3BE The DC variable speed drive product Mentor II current range 25A-1850A, single quadrant and four quadrant versions, has been designed and manufactured in accordance with the following European harmonised, national and international standards: EN60249...

  • Page 5: Features Of Mentor Ii

    Mentor II parameters specific applications. • PID speed loop algorithm. Mentor II is equipped with a range of parameters designed to give the • Provision for encoder inputs for position control. utmost flexibility of application to industrial requirements. The •...

  • Page 6: Safety Information

    Safety Information Within the European Union, all machinery in which this product is used must comply with the following directives: 98/37/EC: Safety of Machinery Warnings, Cautions and Notes 89/336/EEC: Electromagnetic Compatibility. A Warning contains information which is essential for Safety of personnel avoiding a safety hazard.

  • Page 7: Introduction

    Introduction Mentor II is the latest family of advanced, fully microprocessor-controlled DC variable speed industrial Drives. The range of output current is from 25A to 1850A. All sizes share control, monitoring, protection and serial communications features. All units are available alternatively in either single-ended or four- quadrant configuration.

  • Page 8: Control

    Figure 3-3 Dual bridge or parallel-pair 3-phase thyristor (SCR) user-written and internally-monitored parameter values. arrangement for a 4-quadrant DC motor drive For this reason, the Mentor II Drive is equipped with a dedicated microprocessor, and with software which is configured by the +M, +I parameters written to it by the user.

  • Page 9: Data

    Where the local ambient temperature is above 40°C (104°F), derate by 1.5% per °C up to 55°C (0.75% per °F up to 131°F). Enclosure Ingress Protection Mentor II Drives are constructed in accordance with European IP00 specification. Mentor II Drives are suitable for mounting in NEMA ingress-protected enclosures.
  • Page 10 4.2.2 Fuses and cabling Mentor thyristors l t values for fusing The AC supply to the Drive must be fitted with suitable 480V 525V 660V protection against overload and short-circuits. The Drive Model Part no Part no Part no following table shows recommended fuse ratings. Failure to observe this recommendation will cause a M25/M25R 2435-0026...
  • Page 11 4.2.4 Losses 4.2.6 Field Current Rating Losses are equivalent to 0.5% of Drive rated output across the range. Drive type & Field Current Fuse The following table lists the losses in kW and HP for all models, at 400 V model Rating (A) FS1, FS2, FS3...

  • Page 12: Mechanical Installation

    OFF when the Drive is turned on. An automatic changeover switching arrangement is recommended. Mentor II Drives are not to be installed in classified Hazardous Areas unless correctly mounted in an approved enclosure and certified. Figure 5-1 (Refer also to Section 6.1.2, Hazardous Areas.)
  • Page 13 It is essential to include any other heat-generating equipment in the are not equipped with a built-in fan to ensure air circulation. value for PI. C (for all Mentor II Drives) Enclosure ventilation If a high Ingress Protection rating is not a critical factor, the enclosure can be smaller if a ventilating fan is used to exchange air between the inside and the outside of the enclosure.
  • Page 14 NOTE The diagram shows terminals A1 and A2 for FOUR-QUADRANT drives only. For SINGLE-QUADRANT drives, the locations of A1 and A2 are REVERSED. FLOW Unit Dimensions 370 14 / M105 M105R M210 For M25 to M75R M210R = 150mm 5 / in) For M105 to M210R Fans = 195mm 7 / in)
  • Page 15 Figure 5-4 M350(R) to M825(R) Drive Dimensions Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 16 Not to Scale FLOW Metric dimensions are exact Inch dimensions are calculated OUTPUT terminals INPUT terminals Units Mxxx Dimensions 21 / Units MxxxR Dimensions 1015 39 / Common Dimensions 17 / 15 / 12 / 48.5 1 / 18 / 20 / Terminal pads drilled 2 holes 12mm ( / in) clearance...

  • Page 17: Electrical Installation

    Electrical Installation 6.1.4 Control System Earthing (Grounding) External AC control circuits, for example, contactors, should be supplied Installation Criteria (from any two phases of the supply) through an isolating transformer equipped with an earthing (grounding) shield (screen) between the 6.1.1 Safety primary and secondary as shown in Figure 6-2 and Figure 6-3.

  • Page 18: Power Connections

    Power Connections Refer to Figure 6-2 and Figure 6-3. Figure 6-2 Single quadrant power connections Access to the power terminals of the smaller Drives is gained by opening 6.2.1 Motor Rotation the front cover, which is secured by two captive screws, one at each Check that the direction of rotation is as required as soon as the Drive is upper corner, and hinged at the bottom (Figure 6-1).
  • Page 19 Figure 6-3 Four quadrant power connections Mentor ll User Guide Issue Number: 12 www.controltechniques.com...

  • Page 20: Current Feedback Burden Resistors

    Overvoltage suppression Current Feedback Burden Resistors The Mentor II Drive contains overvoltage suppression components to To allow the use of a motor which has a lower rating than the Drive, the protect the thyristors from high voltage pulses (transients or spikes) current feedback has to be re-scaled by changing the burden resistors appearing between the phases because of lightning strikes etc.

  • Page 21: Control Connections

    Control Connections Isolation The control circuits and terminals are isolated from the Refer to Figure 6-2, Figure 6-3, Figure 6-4, and Figure 6-5. Also section power circuits only by basic insulation to IEC664-1. The 6.5 Terminals index on page 18 and section 6.6 Terminals classified on installer must ensure that all external control circuits page 19.

  • Page 22: Terminals Index

    Terminals index Terminals are located on PCB MDA2B, Figure 6-1 and Figure 6-4 Terminal Description Type Programmable Block Number +10V Reference supply -10V Reference supply Speed reference Analog input 4, 5, 6, 7 General purpose GP1, GP2, GP3, GP4 Analog inputs Motor thermistor (thermal) Analog input Tachogenerator (tachometer) negative...

  • Page 23: Terminals Classified

    Terminals classified Encoder (pulse tachometer) - Reference & Feedback Channel A must lead channel B for forward rotation. Analog outputs Terminal block TB2, terminals 11 to 14 inclusive. Connections for: Armature current indication, 5mA Drive capability. Three undedicated outputs, 5mA Drive capability. Output voltage range - Serial Encoder 10V to +10V.

  • Page 24: Operating Procedures

    Operating Procedures Keypad and Displays Figure 7-1 Keypad The keypad serves two purposes: DISPLAYS 1. It allows the operator to configure the Drive to match particular 1. Index applications and to change its behavior in a variety of ways, for The lower four-digit display indicates menu number to the left of the example by altering the times of acceleration and deceleration, (permanent) decimal point, and parameter number to the right.

  • Page 25: Setting Up To Run

    Essential data accordance with Chapter 8 Parameter Set , and Figure 6-2, Figure 6-3 Before attempting to tune a Mentor II to operate a particular load, collect and Figure 6-4. Before attempting to run the Drive, there are further the following information from the nameplate of the motor, connections and settings - some optional - to make or to be considered.
  • Page 26 To gain access to these parameters and set the values select parameter Current Range 00 and enter 200. The Mentor II M75 provides for a field current range of either 2A This permits access to all required parameters. maximum or 8A please refer to the table in the description of parameter 06.11.
  • Page 27 (Normally, if the field is disconnected, the rotor of a shunt wound motor will not move.) Mentor II units from M25 through to M210 contain an internal field regulator and do not require the field to be disconnected.

  • Page 28: Parameter Set

    All parameters, of either kind, are either Read Only (RO) or Read-Write (RW). The parameter set with which Mentor II Drives are equipped is divided into two further groups for operational convenience. Those which are ordinarily needed for setting the Drive up at the installation and start-up stage can be called up whenever the Drive is powered on, and are called the visible parameters.
  • Page 29 8.1.6 Procedure The procedure for selecting and changing a parameter is shown in Figure 8-1, described in the following section, and also on the keypad itself. Power On INDEX display 00.00 SELECT required menu SELECT Level 1 Security Procedure required parameter SET INDEX to xx.00...

  • Page 30: Security

    Security 8.2.2 Level 1 Security to access the Visible RW Parameters (Figure 8-1) After selecting a parameter number and pressing MODE - • UP or DOWN to set index to zero • If the parameter data flashes, the user can change the value •...

  • Page 31: Index Of Parameters

    5.05 The Index of Parameters lists the sixteen Menus, followed by the basic 6.21 data for each parameter of the Mentor II Parameter Set listed menu by 7.08 to 7.23 menu. For detailed descriptions of parameters please refer to section 8.12 to 8.20...
  • Page 32 Menu 00 User Library - Refer to Menu 11 Contains ten parameters (00.01 to 00.10).The user sets parameters 11.01 to 11.10 to any parameter numbers most often required or used. These can then be accessed directly through the corresponding numbers 00.01 to 00.10, avoiding the need to call up different menus. Menu 01 Speed Reference - selection of source and limits Number...
  • Page 33 Menu 03 Speed Feedback - selection and Speed Loop Number Description Range Type Default 03.01 Final speed demand ±1000 03.02 Speed feedback ±1000 03.03 Speed feedback (rpm) ±1999 03.04 Armature voltage ±1000 03.05 IR Compensation output ±1000 03.06 Speed error ±1000 03.07 Speed loop output...
  • Page 34 Menu 04 Current - selection and limits Number Description Range Type Default 04.01 Current demand ±1000 04.02 Final current demand ±1000 04.03 Over-riding current limit ±1000 04.04 Current limit (taper start point) 0 ~ 1000 +1000 04.05 Current limit Bridge 1 0 ~ 1000 +1000 04.06...
  • Page 35 Menu 05 Current Loop Number Description Range Type Default 05.01 Current feedback ±1000 05.02 Current feedback (amps) ±1999 05.03 Firing angle 277 ~ 1023 05.04 Slew rate limit 0 ~ 255 05.05 Maximum current (scaling) 0 ~ 1999 (rating) 05.06 Overload threshold 0 ~ 1000 + 700...
  • Page 36 Menu 06 Field Control Number Description Range Type Default 06.01 Back emf 0 ~ 1000 06.02 Field current demand 0 ~ 1000 06.03 Field current feedback 0 ~ 1000 06.04 Firing angle 261 ~ 1000 06.05 IR compensation 2 output ±1000 06.06 IR compensation 2...
  • Page 37 Menu 07 Analog Inputs and Outputs Number Description Range Type Default 07.01 General purpose input 1 ±1000 07.02 General purpose input 2 ±1000 07.03 General purpose input 3 ±1000 07.04 General purpose input 4 ±1000 07.05 Speed reference input ±1000 07.06 RMS input voltage 0 ~ 1000...
  • Page 38 Menu 08 Logic Inputs Number Description Range Type Default 08.01 F1 input run permit 0 or 1 08.02 F2 input inch reverse 0 or 1 08.03 F3 input inch forward 0 or 1 08.04 F4 input run reverse 0 or 1 08.05 F5 input run forward 0 or 1...
  • Page 39 Menu 09 Status Outputs Number Description Range Type Default 09.01 Status 1 output 0 or 1 09.02 Status 2 output 0 or 1 09.03 Status 3 output 0 or 1 09.04 Status 4 output 0 or 1 09.05 Status 5 output 0 or 1 09.06 Status 6 output (relay)
  • Page 40 Menu 10 Status Logic & Diagnostic Information Number Description Range Type Default 10.01 Forward velocity 0 or 1 10.02 Reverse velocity 0 or 1 10.03 Current limit 0 or 1 10.04 Bridge 1 enabled 0 or 1 10.05 Bridge 2 enabled 0 or 1 10.06 Electrical phase-back...
  • Page 41 Menu 11 Miscellaneous NOTE Parameters 11.07 through to 11.10 have functions associated with the MD29 PCB. Refer to the MD29 Users Guide. Number Description Range Type Default 11.01 Parameter 00.01 0 ~ 1999 11.02 Parameter 00.02 0 ~ 1999 11.03 Parameter 00.03 0 ~ 1999 11.04...
  • Page 42 Menu 13 Digital Lock Number Description Range Type Default 13.01 Master encoder counter 0 ~ 1023 13.02 Slave encoder counter 0 ~ 1023 13.03 Master counter increment ±1000 13.04 Slave counter increment ±1000 13.05 Position error ±1000 13.06 Precision reference (lsb) 0 ~ 255 13.07 Precision reference (msb)
  • Page 43 Menu 15 Applications Menu 1 Number Description Range Type Default 15.01 RO variable 1 ±1999 15.02 RO variable 2 ±1999 15.03 RO variable 3 ±1999 15.04 RO variable 4 ±1999 15.05 RO variable 5 ±1999 15.06 Real RW variable 1 ±1999 + 000 15.07...
  • Page 44 Menu 16 Applications Menu 2 Number Description Range Type Default 16.01 RO variable 1 ±1999 16.02 RO variable 2 ±1999 16.03 RO variable 3 ±1999 16.04 RO variable 4 ±1999 16.05 RO variable 5 ±1999 16.06 Real RW variable 1 ±1999 + 000 16.07...

  • Page 45: Advanced Parameter Descriptions

    Advanced Parameter Descriptions Menu 1: Speed Reference 01.05 Inch reference There are four speed references, 01.17, 01.18, 01.19 and 01.20. Each of the four can be given any single value in the range 1000 forward to 1000 in reverse (the value 1000 representing full speed), and can be rewritten ô...
  • Page 46 01.14 Reference selector 1 01.10 Bipolar reference selector 4 Quadrant ô ð ô ð The two reference selectors 01.14 and 01.15 in combination allow any one of the four speed references 01.17 to 01.20 to be selected. 1 Quadrant 1.14 1.15 Reference Selected 1.17...

  • Page 47: Menu 02: Ramps

    Menu 02: Ramps The principal alternatives available for setting ramps are as follows - 02.08 Forward acceleration 2 1. No ramps at all, bypassing the ramp functions. 2. A selection of forward and reverse ramps for normal run conditions 02.09 Forward deceleration 2 and an optional separate ramp for inching.

  • Page 48: Menu 03: Feedback Selection And Speed Loop

    Menu 03: Feedback Selection and Speed Loop The principal inputs are the post-ramp reference 02.01 and the hard 03.05 IR Compensation output speed reference 03.18. The post-ramp reference can be summed with or replaced by the hard speed reference. The speed reference can, alternatively, be the hard speed reference alone.
  • Page 49 03.10 Speed loop integral gain 03.14 Encoder feedback scaling ô 0~255 ð ô 0~1999 ð +419 The factor by which the speed error is multiplied to produce the The value should be set to correspond with the maximum speed of the correction term.
  • Page 50 03.18 Hard speed reference 03.24 Derivative term source ô ð ô ð ±1000 (07.11) 1,2 or 3 Speed reference fed into the speed loop without passing through the The derivative term of the PID in the speed loop may use one of three ramps.

  • Page 51: Menu 04: Current Selection And Limits

    Menu 04: Current Selection and Limits The principal input is the speed loop output 03.07 in combination, for 04.06 Current limit bridge 2 torque- or current-control modes, with the torque reference 04.08. These inputs become the current demand to which an offset or trim option may be applied.
  • Page 52 Basic current - or torque - control mode In this mode, the torque reference 04.08 is the input to the current loop 04.13 Mode bit 1 and is subject to the limitations of the over-riding current limit 04.03, the Bridge 1 and Bridge 2 limits 04.05 and 04.06, and to the current slew rate 05.04.
  • Page 53 Coiler/uncoiler control mode Refer to Figure 8-4 and Figure 8-5. 04.14 Quadrant 1 enable This mode allows torque to be applied in either sense, for acceleration or deceleration, while preventing uncontrolled increase in speed or reversal if the load becomes zero. When the torque demand is in the sense opposite to that of speed ô...
  • Page 54 04.20 Current taper 1 threshold 04.23 Current taper 2 slope ô ð 0 ~ 1000 +1000 ô 0 ~ 255 ð Sets a threshold value of speed feedback, beyond which 04.24 changes Sets the rate of change of armature I-limit with respect to speed in either to 1 to indicate that the threshold has been exceeded, and is the starting direction of rotation, above the threshold set by 04.21.

  • Page 55: Menu 05: Current Loop

    Menu 05: Current Loop This is the final stage in the processing of the speed and torque 05.04 Slew rate limit references and feedbacks to determine the final firing angle signal. The normal principal input is the final current demand, which is subject to the slew rate limit, summed algebraically with the current feedback and further modified by whatever settings may have been applied to the ô...
  • Page 56 05.08 Overload integrating time (cooling) 05.11 Actual overload ô 0 ~ 255 ð ô 0 ~ 1999 ð Integrating time for 05.06. For use in conjunction with 05.07, such that Monitors the value of the integrating current-time overload. When the 05.07 <...
  • Page 57 05.15 Motor constant 05.20 Enable direct firing angle control ô 0 ~ 255 ð ô 0 or 1 ð 0, disabled This parameter is used to scale the current demand such that the control When enabled, the firing angle 05.03 is controlled by the value of the loop correctly predicts the firing angle in the discontinuous current post-ramp reference 02.01.
  • Page 58 05.24 Series 12 - pulse operation Reduced hysteresis for bridge 05.28 changeover ô 0 or 1 ð 0, disabled ô 0 or 1 ð 0, disabled This parameter should be set for operation in either single- or four- quadrant 12-pulse mode. Parameter 05.23 (see above) is read by the There is hysteresis on a bridge changeover to prevent oscillation software only at power-on and during a cyclic reset (a reset when the between the two bridges under lightly loaded conditions.

  • Page 59: Menu 06: Field Control

    Menu 06: Field Control The Mentor II is equipped with field control as part of the on-board 06.05 IR compensation 2 output software. If a motor is being used with an uncontrolled (fixed) field supply, this menu does not apply.
  • Page 60 Set 06.17 = 1 to double the integral gain if less overshoot is desired. 06.18 Enable speed gain adjustment NOTE Mentor II can be used with an Issue (rev) 1 MDA3 card, maximum current 5A. Parameter 06.11 then has the range 101 to 110 and a ô 0 or 1 ð...
  • Page 61 06.20 Alternative IR comp. 2 selector ô 0 or 1 ð 0 (= 03.08) Determines the source of the IR Compensation 2. The source selection may be either the Speed Error Integral 03.08 (set to 0) or the final current demand 04.02 (set to 1). 06.21 Firing angle front endstop ô...

  • Page 62: Menu 07: Analog Inputs & Outputs

    Menu 07: Analog Inputs & Outputs Scaling parameters have a multiplying range from 0.001 to 1.999 (a 07.05 Speed reference input multiplier of zero would give the parameter a null value). Source and Destination parameters define a parameter to be used as either input or output, thereby defining the function of the programmable ô...
  • Page 63 07.11 GP1 destination 07.18 GP3 scaling ô 0 ~ 1999 ð +318, hard speed ref. ô 0 ~ 1999 ð +1000 Selects the destination of analog input 1 via terminal TB1-04. Sets the scaling for the signal from source GP3 via terminal TB1-06. A changed value becomes effective only when the RESET pushbutton is 07.18 ScalingFactor...
  • Page 64 07.24 Reference encoder scaling 07.29 Invert GP3 and GP4 analog inputs ô 0 ~ 1999 ð +419 ô 0 or 1 ð Sets the scaling for signals from the reference encoder (pulse tach.) When set to 1 the polarity of GP3 and GP4 analog inputs will be connected to terminal socket PL4.

  • Page 65: Menu 08: Digital Inputs

    Menu 08: Digital Inputs 08.05 F5 input run forward 08.01 F1 input run permit ô 0 or 1 ð ô 0 or 1 ð 0 = input not active 1 = input active 0 = stop Drive Monitors the control input from terminal TB3-25 and indicates status. 1 = start enabled The Drive will respond to this input as run forward command only if the Monitors the Drive start-permit control input from terminal TB3-21 and...
  • Page 66 08.11 Enable input 08.18 F8 destination ô 0 or 1 ð ô 0 ~ 1999 ð +000 0 = disable Defines the destination of external logic input at terminal TB3-28. 1 = enable Effective only after RESET. Monitors the Drive enable input from terminal TB4-31 and indicates status.
  • Page 67 08.34 Enable run forward 08.22 Invert input F2 08.23 Invert input F3 ô ð 0 or 1 08.24 Invert input F4 0 = not enable 08.25 Invert input F5 1 = enable Run Forward When 08.21 = 1, normal logic functions disabled, 08.34 can enable Run Fwd.

  • Page 68: Menu 09: Status Outputs

    Menu 09: Status Outputs Status Output parameters define a parameter to be used as a source, 09.12 Status 1 delay thereby defining the function of programmable output terminals. Menu 09 contains three status source groupings, each of which can be inverted.
  • Page 69 09.22 Invert status 4 output ô 0 or 1 ð 09.23 Status 5 source ô 0 ~ 1999 ð +1006 09.24 Invert status 5 output ô 0 or 1 ð 09.25 Status 6 source (relay) ô 0 ~ 1999 ð +1009 09.26 Invert status 6 output...

  • Page 70: Menu 10: Status Logic & Diagnostic Information

    Menu 10: Status Logic & Diagnostic Information All real (not bit) RO parameters are frozen at the instant of tripping as an 10.04 Bridge 1 enabled aid to diagnosis of the fault. They remain in this condition until the Drive is reset.
  • Page 71 10.09 Zero speed 10.14 Field loss ô 0 or 1 ð ô 0 or 1 ð 0 = speed not zero 0 = field healthy (normal) 1 = zero speed 1 = field failed Set if speed feedback 03.02 < zero speed threshold 03.23. Refer to Indicates that no current is being drawn from the internal field supply (or 10.01 and 10.02 the FXM5 optional external field control unit if installed).
  • Page 72 10.18 Sustained overload 10.22 Heatsink overtemperature ô 0 or 1 ð ô 0 or 1 ð 0 = sustained overload not detected 0 = healthy (normal) 1 = sustained overload detected 1 = trip Indicates that current feedback 05.01 has exceeded the overload 10.22 = 1 indicates thyristor (SCR) stack overtemperature, >100 C (on threshold 05.06 for a length of time determined by the overload time...
  • Page 73 10.28 The trip before 10.27 10.33 Disable heatsink overtemperature trip ô 0 ~ 255 ð ô 0 or 1 ð Record of the trip before that which is saved in 10.27. 0 = heatsink overtemperature trip enabled The four parameters 10.25 to 10.28 provide a permanent memory of the Prevents the Drive from tripping when heatsink temperature sensor last four trips.

  • Page 74: Menu 11: Miscellaneous

    Menu 11: Miscellaneous A Drive reset is required before the value takes effect. User defined menu Parameters 11.01 through to 11.10 define the parameters in the user- 11.14 Reserved defined Menu 00. For example, if the user wishes parameter 00.01 to display speed in rpm (03.03), parameter 11.01 (corresponding to 00.01) should be set to 303.
  • Page 75 NOTE In order to maximize the mains dip ride-through capability of the Mentor II it is necessary to connect the circuit shown in Figure 8-7. Software version V3.1.0, or later, must be installed. Analog input GP2 (refer to Menu 07) is set up as a mains healthy (AC power normal) input when parameter 11.24 = 1.

  • Page 76: Menu 12: Programmable Thresholds

    Menu 12: Programmable Thresholds 12.10 Threshold 2 hysteresis 12.01 Threshold 1 exceeded ô 0 ~ 255 ð ô 0 or 1 ð 0 = healthy (normal) 12.11 Invert threshold 2 output 1 = threshold exceeded 12.02 Threshold 2 exceeded ô 0 or 1 ð...

  • Page 77: Menu 13: Digital Lock

    Menu 13: Digital Lock 13.08 Position loop gain 13.01 Master encoder counter ô 0 ~ 255 ð ô 0 ~ 1023 ð Determines the amount of velocity correction per unit of position error. The setting thus determines how quickly the loop responds to a disturbance, and thus affects the motor output shaft position.
  • Page 78 13.13 Precision reference latch ô 0 or 1 ð 0 = use last values 1 = use updated values The two Precision Reference values, 13.06 and 13.07, cannot be changed simultaneously. To prevent the Position Loop reading inconsistent values during the change, parameter 13.13 = 0 (default) enables the Position Loop to continue to use the last values while the change is taking place.

  • Page 79: Menu 14: Md29 System Set-Up

    Menu 14: MD29 system set-up 14.07 Global run time trip enable NOTE The set-up parameters take effect only after the MD29 or Drive has been reset, or when a RENIT instruction in a DPL program has been ô 0 or 1 ð...
  • Page 80 14.14 Encoder time base select ô 0 or 1 ð This parameter sets the timebase for the ENCODER Task. 0 = 5ms 1 = 2.5ms 14.15 Reserved ô 0 or 1 ð 14.16 Flash store request ô 0 or 1 ð...

  • Page 81: Menus 15 And 16: Applications Menus

    Menus 15 and 16: Applications Menus These menus are free for use by any application program within a MD29. 15.01 RO variable 1 ~ 5 16.01 15.05 RO variable 1 ~ 5 16.05 ô ±1999 ð ô ±1999 ð 15.06 Real RW variable 1 ~ 5 15.10 16.06...
  • Page 82 Special Parameters in Menu 15 Special Parameters in Menu 16 15.60 Ratio 1 wide integer 16.62 CTNet diagnostic parameter ô ð ô ð 0 ~ 65535 This parameter is the equivalent of parameters 15.16 and 15.17, such This parameter indicates the state of the CTNet network. that Ratio 1 in the Digital Lock software can be written simultaneously, A value greater than 0 indicates a healthy network, with the value removing the need for the latch, 15.31.

  • Page 83: Menu Logic Diagrams

    Menu logic diagrams Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 84 Mentor ll User Guide www.controltechniques.com Issue Number: 12...
  • Page 85 Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 86 Mentor ll User Guide www.controltechniques.com Issue Number: 12...
  • Page 87 Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 88 Mentor ll User Guide www.controltechniques.com Issue Number: 12...
  • Page 89 Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 90 Mentor ll User Guide www.controltechniques.com Issue Number: 12...
  • Page 91 Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 92 Mentor ll User Guide www.controltechniques.com Issue Number: 12...
  • Page 93 Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 94 Mentor ll User Guide www.controltechniques.com Issue Number: 12...

  • Page 95: Diagnostic Procedures

    Diagnostic Procedures Trip codes Mnem. Code Reason for the trip Armature overcurrent An instantaneous protection trip has been activated due to excess current in the armature circuit Armature open circuit Drive has detected that the firing angle has advanced but no current feedback has been detected Current (control) loop open circuit If the input reference is either 4-20mA or 20-4mA, this trip indicates that input current is <3.0mA EEprom failure Indicates that an error has been detected in the parameter set read from the EEprom at power-up...

  • Page 96: Serial Communications

    Control key down while making a single-letter keystroke. Of the 32 control characters in the If you have problems... ASCII set, the seven in the following table are used in Mentor II serial Cannot go on-line: communications.
  • Page 97 If the user wishes to set variable to a higher resolution, six digits must be clarity. For example, to send menu 04, parameter 26, write 0 4 2 6. written in the data field. Mentor II then recognizes the request for higher resolution. For example, to set the speed demand to 47.65% of...
  • Page 98 Using Mentor on a network with other CT Drives Invalid Parameter Number Unlike some other Control Techniques products such as the Unidrive or If the host sends a parameter number which the Drive does not the MD29 card, the Mentor does not support the Group Addressing recognize, e.g.
  • Page 99 Global Addressing The Mentor II Drive also supports the use of Global Addressing. This is where a message can be broadcast to all Drives on the network - to use this, the controller will send its message to address 00. Note that when global addressing is used, the Drives will not respond to any command messages.

  • Page 100: Option Cards

    Offers slave positioning or speed control using linear or S-ramp control for the velocity profile; digital lock with rigid and non-rigid The FXM5 unit enables a Mentor II Drive to operate a motor with a modes with a slave ratio of 8-decimal places accuracy;...
  • Page 101 (FS3 and FS4). If a field current in excess of 9A is required the fuses must be replaced by HRC fuses of appropriate rating. Maximum Field Current, Digital Control Mentor II Software version V4.3.0 onwards. NOTE NOTE The Field Controller will weaken the field even though the armature Issue (rev) 2 FXM5 must not be used with earlier versions of Mentor voltage clamp may be active.

  • Page 102: Electromagnetic Compatibility

    For more detailed information, refer to the Mentor II EMC datasheet. instructions. The provision of this data does not form part of any contract The Drive complies with the following international and European or undertaking.
  • Page 103 Emission The capacitors must be wired in as close as possible approximation to a ‘Kelvin’ connection, minimising the length of the wiring between the For installation in the “second environment”, capacitors and the power circuit. ie, where the low voltage supply network does not supply domestic premises, no filter is required in order to meet IEC61800-3 (EN61800-3).
  • Page 104 Refer to the Mentor II EMC datasheet. It is the responsibility of the owner or user to ensure that the installation of the Drive and the way it is...
  • Page 105 Use this page for notes. Mentor ll User Guide Issue Number: 12 www.controltechniques.com...
  • Page 106 (field connections are shown for M25 to M210). Conducted emissions from the main thyristor convertor suppressed by line to earth capacitors and standard line reactors. For more detailed information, refer to the Mentor II EMC datasheet. Mentor ll User Guide www.controltechniques.com...
  • Page 107 Refer to the EMC Data Sheet Alternative location for information on the following: of fuses Line-to-ground capacitors and discharge resistors Line reactors RF chokes for the field regulator RFI filters φ2 φ1 RFI filter LINE RFI filter Line reactors LOAD φ2 φ1 If an optional MD29 card is installed, fit a ferrite ring...
