motor installation
Outline Drawings - Frame Size 190
Shaft Key Detail
(Option A)
DIRECTION
OF ROTATION
FOR UVW=
CLOCKWISE
T
R
S
UNIMOTO
N
V
Dimensions - Frame Size 190
FRAME SIZE
Dimension / Length suffix
A
Length Overall (Unbraked)
A
Length Overall (Braked)
B
Body Length (Unbraked)
B
Body Length (Braked)
C
Flange Square
D
Flange Thickness
E
Register Diameter
F
Register Length
G
Terminal Box to Power Connect C/L
G
Terminal Box to Front Flange (Unbraked)
1
G
Terminal Box to Front Flange (Braked)
1
H
Fixing Holes Diameter
J
Fixing Hole p.c.d.
K
Overall Height
L
Signal Connector Height
N
Shaft Length (front)
P
Shaft Diameter (front)
Shaft Output Key Dimensions (option A)
R
Shaft Key Length
S
Shaft Key Height
T
Shaft Key to Shaft End
V
Shaft Key Width
C (REF)
S
C
1 HOLE
DRILL 34.0
DEEP &
TAP M12 x
1.75 - 6H
4 HOLES
x 28 DEEP
DIA 'H'
EQUI-SPACED
ON 'J' P.C.D.
190
A
B
C
D
273
327
381
435
327
381
435
489
210
264
318
372
264
318
372
425
190.0
14.5
180.0 (J6)
4.0
173.0
69
123
177
231
123
177
231
285
14.5 (H14)
215.0
256.0
161.1
58.0
32.0
49.0
35.0
3.1
10.0
A (MAX)
N
B (MAX)
F
T
R
G1 (REF)
D
E
V
P
K
L
G (REF)
75.0
33
