11.3.2

Mounting

11.3.2.1 Installing device on top-hat rail
Hook the device over the upper edge of the top-hat rail and press it on until
the clamp snaps into place.
To remove the device, pull the clamp down with a screwdriver and take the
device off the top-hat rail.
Fig. 43: Installation on a top-hat rail
(1)
(2)
(3)
(4)
70/78
3
1
1
4
Device
Top-hat rail
Upper edge of top-hat
rail
Pressing on the device
2
1
5
(5) Screwdriver
(6) Releasing the clamp
(7) Removing the device
