P(Di) Internal - meteocontrol Power Control Operating Manual

Digital output
Active power procedure via analogue input
Input field
The lowest measured value
The highest measured value
Sensitivity
Issue current control value
Capping the feed-in power
at P
AV
7.1.3

P(DI) internal

With this procedure, the active power P is used as the control value.
The DI requirement is provided by the grid operator as a digital input signal,
e.g. digital ripple control receiver and connected to the internal digital inputs
DI of the WEB`log.
meteocontrol Power Control 03082012 - en
Feedback output
Meaning
Value pair for the definition of the lowest
working point (example: 4.5 mA corresponds
to zero per cent)
Value pair for the definition of the highest
working point (example: 19.5 mA
corresponds to one hundred per cent)
Sensitivity setting: indicates from when a
change to the analogue input results in a
change to the control value (indicated in %)
Control value issue setting: indicates whether
the current input current is fed back on the
analogue current output
Limitation of the feed-in power to P
AV
