General information

Input field
Modbus driver version
Serial interface settings
Input field
Modbus
Baud rate
Data bits \ Parity \ Stop bits
Scan for
Read new device types
The interface used is assigned via the suffix in the file name of the PCU
device type:
Input field
pcu_rtu.mod
pcu_tcp.mod
janitza_umg604_rtu.mod
janitza_umg604_tcp.mod
Save
Note:
meteocontrol Power Control 03082012 - en
Meaning
Current driver software version
Meaning
Modbus protocol used, ASCII or RTU,
standard: RTU
Baud rate of the serial interface
Standard: 9600 Baud
Definition of the serial protocol
Standard: 8/N/1
Modbus message used for scanning
Meaning
PCU Modbus via RTU (standard)
PCU Modbus via TCP
NAG Modbus via RTU (standard)
NAG Modbus via TCP
Saves the settings made
Modbus TCP requires no configuration of the interfaces.
