Web`log Pro Master - Slave - meteocontrol Power Control Operating Manual

Fig. 40: Connection ripple control receiver <> WEB`log
(1)
(2)
(3)
•
If internal WEB`log inputs (WEB`log DIs) are used, feedback signals are
not supported.
•
If Power Control is activated, the digital inputs must not be configured
otherwise by the WEB`log.
•
Ripple control receivers with pulse output are not supported.
A PCU must be used for pulse evaluation.
10.1.2

WEB`log Pro master - slave

110 V
N L AC
230 V
110 V
N L AC
230 V
Fig. 41: Master-slave connection
(1)
(2)
(3)
•
All WEB`log devices must be in the same network (subnet mask).
•
Every WEB`log must be assigned its own IP address.
•
A maximum of two WEB`log devices may be directly connected via a
cross cable.
•
For more than two WEB`log devices, an Ethernet switch is required.
meteocontrol Power Control 03082012 - en
Ripple control receiver
Digital input DI1
Digital input DI2
- + - + - + - + - + -
AI4 AI3 AI2 AI1 DI1 DI1
2
+ -
Phone Ethernet RS485
24 V
- + - + - + - + - + -
AI4 AI3 AI2 AI1 DI1 DI1
2
+ -
Phone Ethernet RS485
24 V
WEB`log PRO Master
WEB`log PRO Slave
Ethernet switch
(4)
(5)
(6)
+ - + - +
DI1 DI1
+ -
RS232 N L
DO1
5
+ - + - +
DI1 DI1
+ -
RS232
DO1
5
(4)
(5)
Digital input DI 3
Digital input DI 4
WEB`log
- + - + - + - +
AI4 AI3 AI2 AI1
110 V
+ -
AC Phone Ethernet
230 V 24 V
4
3
5
Connection WEB`log PRO
master with Ethernet switch
Connection WEB`log PRO slave
with Ethernet switch
- + - + - + - +
DI1 DI1 DI1 DI1
1
+ -
RS485 RS232
DO1
