Details On The Pcu Interface Configuration; Pcu Ip Configuration; Pcu Serial Configuration; Assignment Of The Pcu In Web`log - meteocontrol Power Control Operating Manual

Port
Client ID
Device type
Add
Device configuration
Input field
Address
Client ID
Device type
Save
6.3

Details on the PCU interface configuration

6.3.1

PCU IP configuration

If the PCU is connected to the WEB`log via TCP, depending on the
architecture of the PV system IP network the IP settings of the PCU need to
be changed (IP address, subnet mask).
The meteocontrol device manager service program is required for
configuration. The program can be downloaded from the meteocontrol
download area.
6.3.2

PCU serial configuration

If the PCU is connected to the WEB`log serially via the Modbus RTU, the
Modbus client ID on the device or on the PCU may have to be changed.
Every Modbus client ID may be assigned only once.
This depends on the architecture of the PV system IP network (Modbus
structure and client IDs assigned).
By default, the PCU is serially (Modbus RTU) connected to the WEB`log.
(see section 11.3.3.4 Connection PCU with WEB`log PRO, Modbus RTU).
Note:
6.3.3

Assignment of the PCU in WEB`log

The PCU Modbus client ID is assigned to the PCU device types (see section
6.2).
meteocontrol Power Control 03082012 - en
Input of the IP port
Displays the client ID assigned
Assignment of the device type
Save the assignments
Meaning
Displays the address assigned
Displays the client ID assigned
Displays the device type assigned, version
and interface
Saves the current settings
If the PCU is used with other additional Modbus devices, the
serial bus must be operated with the standard parameters.
21/78
