Functional display Power Control with WEB`log PRO
safer Sun
Fig. 2: Functionality Power Control
(1)
Energy supplier
(2)
Public grid
(3)
Ripple control receiver
(4)
WEB`log master
(5)
Ethernet switch
(6)
WEB`log slave
14/78
1
7
7
7
9
2
P
6
6
11
(7)
Inverter
(8)
Internet
(9)
Web portal
(10)
Power requirements report
(11)
Alert, residual energy balance
Report
meteocontrol Power Control 03082012 - en
3
P
5
8
10
4
