Fig. 26: Active power procedure P(DI) internal
Feedback on the set power level to the energy supplier is not possible with
this procedure.
Contrary to the P(DI) procedure via PCU, use of bitmasks is permitted for the
P(DI) procedure via WEB`log.
Settings
Input field
Digital inputs column (DI 4 -
DI 1)
Configuration column
Capping the feed-in power at
P
AV
38/78
Meaning
Configurable for up to 16 different power
levels. Green indicates what input must be
activated
Power requirement in per cent when
occupying the relevant digital inputs
Limitation of the feed-in power to P
