Reactive power procedure via analogue input
Input field
Lowest measurement value
Highest measurement value
Sensitivity
Issue current control value
meteocontrol Power Control 03082012 - en
Meaning
Indicated in mA and %. Value pair for the
definition of the lowest working point
(example: 4.3mA corresponds to factor
0.975 – overexcited)
Indicated in mA and %. Value pair for the
definition of the highest working point
(example: 19.7mA corresponds to factor
0.995 – underexcited)
Sensitivity setting: indicates from when a
change to the analogue input results in a
change to the control value
Control value issue setting: indicates
whether the current input current is fed back
on the analogue current output
