(no slaves)]
Master (alle Slaves) [Master
(all slaves)]
Master (ausgewählte Slaves)
[Master (selected slaves)]
Master (Slavegruppen)
[Master (slave groups)]
Slave group
IP address
Active
Note:
WEB`log Pro definition as a slave
If the WEB`log is operated as a slave, control values must be defined that
are used in the event of a communication failure master->slave WEB`log.
Fig. 17: Definition WEB`log slave general broadcast
meteocontrol Power Control 03082012 - en
slaves
Transfers control value information as a
broadcast to all slaves available
Transfers control value information to all
slaves selected that are activated in the
address list
Transfers control value information as a
broadcast to all slave groups
Slave group ID for addressing
Input and activation for up to 20 slave
WEB`logs
Activates the address field
The data logger activated as the master sends information
on active and reactive power values to slaves. Active and
reactive power procedures can be set and configured on the
master only.
