Installation within a spare slot position
WARNING: It is essential that, when other option cards are introduced which use
The equipment must be installed such that with the exception of the connections to
the host, clearance and creepage distances shown in the table below are
maintained between the adapter and any other assemblies which use or generate
a voltage shown in the table below.
Clearance
X mm
2.0
2.6
4.0
4.0
The larger distance shown in brackets applies where the local environment within
the host is subject to conductive pollution or dry non-conductive pollution which
could become conductive due to condensation. Failure to maintain these minimum
distances would invalidate the approval.
The clearance distance X is the shortest distance in air between two points. The
creepage path Y (along surfaces) is the shortest distance between the same two
points.
VoIPon www.voipon.co.uk
or generate a hazardous voltage, the minimum creepages and
clearances specified in the table below are maintained. Suitable
user protection to ensure compliance with EN 60950 should be
present on the card. A hazardous voltage is one which exceeds
42.4 V peak a.c or 60 V d.c. If you have any doubt, seek advice from
a competent engineer before installing other adapters into the host
equipment.
Creepage
Y mm
2.4 (3.8)
3.0 (4.8)
5.0 (8.0)
6.4 (10.0)
International Regulatory Information
sales@voipon.co.uk
Voltage used or generated by other parts of
the host or expansion card Vrms or Vdc
up to 50
up to 125
up to 250
up to 300
