Adaptadores Diva Server PRI 2.0, Diva Server PRI 3.0 y
Diva Server V-PRI
Los adaptadores Diva Server PRI 2.0, 3.0 y V-PRI tienen cuatro LEDs (véase la
figura):
Diva Server PRI 2.0
amarillo
azul
En la siguiente tabla se muestra la función de cada LED:
Color
Estado
amarillo
apagado
encendido
rojo
apagado
encendido
azul
apagado
encendido
verde
apagado
encendido
114
VoIPon
www.voipon.co.uk
rojo
verde
Descripción
Funcionamiento normal.
La estación remota tiene problemas de sincronización (remote
alarm / yellow alarm).
Funcionamiento normal.
Al receptor no le llega ninguna señal (loss of signal / red alarm).
Funcionamiento normal.
Las tramas recibidas no están bien sincronizadas (alarm
indication signal / blue alarm).
Nivel 2 inactivo. Compruebe la configuración del nivel 2, es decir,
el protocolo del canal D, la central telefónica, etc.
Nivel 2 activo. El nivel 2 está activo siempre que el adaptador
Diva Server PRI funcione correctamente.
Problemas y Soluciones
sales@voipon.co.uk
Diva Server PRI 3.0
Diva Server V-PRI
Diva Server PRI PCIe
rojo
verde
Tel: +44 (0)1245 808195
amarillo
azul
Fax: +44 (0)1245 600030
