Bus type
CPU
Memory
IRQ levels
I/O base addr. (hex)
Shared memory range
DSPs
Dimensions in mm
(length x height)
PCB
Low profile bracket
Bracket
Dimensions in mm
PCB
Bracket and retainer
Data transfer in kbps
B-channels
D-channel (PRI)
Channelized T1
Plug&Play
Power safe mode
Port
Physical interface
Power requirements
44
VoIPon www.voipon.co.uk
Diva Server PRI PCIe
Diva Server V-PRI PCIe
PCIe 1.0a x1 lane (3.3/12 V)
32 Bit RISC CPU, 300 MHz
64 MB SDRAM
Allocated by PC BIOS
either 2, 24, or 31 ADSPs 2185
PRI/E1/T1-CTI PCIe:
167.52 x 64.41
181.36 x 80.06
181.36 x 120.88
PRI/T1-24 PCIe, PRI/E1-30 PCIe, V-PRI PCIe:
312.00 x 106.68
352.17 x 126.37
23 or 30 x 64
24 x 56
Female RJ45 (ISDN PRI)
Primary rate interface or channelized T1 interface
PRI/E1/T1-CTI PCIe:
0.96 A @ +3.3 V typ.
0.04 A @ +12 V typ.
PRI/T1-24 PCIe, V-PRI/T1-24 PCIe:
2.1 A @ +3.3 V typ.
0.03 A @ +12 V typ.
PRI/E1-30 PCIe, V-PRI/E1-30 PCIe:
2.3 A @ +3.3 V typ.
0.03 A @ +12 V typ.
Technical Specifications
sales@voipon.co.uk
8 MB
1 x 64
yes
