Technical Specifications

Environmental requirements:
• Operating temperature: 10 degrees C to 50 degrees C
• Maximum tolerance in voltage fluctuation: according to the respective
PCI specification (PCI/PCIe)
Bus type
CPU
Memory
IRQ levels
I/O base addr. (hex)
Shared memory
range
DSPs
Dimensions in mm
(length x height)
PCB
Low profile bracket
Bracket
Data transfer in kbps
B-channels
D-channels
Plug&Play
Power safe mode
Ports
Physical interfaces
Power requirements
40
VoIPon www.voipon.co.uk
Diva Server BRI-2M 2.0
Diva Server V-BRI-2
32 Bit RISC CPU, 100 MHz
8 MB SDRAM
Allocated by PC BIOS
8 MB
2 ADSP 2185
167.52 x 64.41
181.36 x 80.06
181.36 x 120.88
2 x 64
1 x 16
Female RJ45 (ISDN BRI)
ISDN basic rate interface
0.33 A @ +5 V typ.
Technical Specifications
sales@voipon.co.uk
Diva Server 4BRI-8M 2.0
Diva Server V-4BRI-8
PCI (3.3/5.0 V)
16 MB SDRAM
16 MB (memory)
64 Kbyte (local registers)
8 ADSP 2185
174.63 x 106.68
187.84 x 126.37
4 x 2 x 64
4 x 16
yes
4 x Female RJ45 (ISDN BRI)
4 x ISDN basic rate interface
0.58 A @ +5 V typ.
