- Page 1 Diva Server Adapters Installation Guide www.eicon.com/divaserver...
- Page 2 Eicon Networks may make improvements and/or changes in the products and/or programs described in this publication at any time. If you wish to make comments about your Eicon Networks server adapter or the corresponding software, address them by E-mail to: divaserver@eicon.com.
- Page 3 License Under the terms and conditions of this license agreement: • The software may be used only in conjunction with a legally acquired Eicon Networks ISDN adapter; • You may make as many copies of the Eicon Networks software components and documentation as you wish for your own personal use;...
- Page 4 Products requiring limited warranty service during the warranty period should be delivered to Eicon Networks with proof of purchase. If the delivery is by mail, you agree to insure the product or assume the risk of loss or damage in transit. You also agree to prepay shipping charges to Eicon Networks and to use the original shipping container or equivalent.
-
Page 6: Table Of Contents
Contents Introduction ... 7 Ordering Your ISDN PRI or T1 Line ... 9 Provisioning an ISDN PRI connection... 10 Provisioning a channelized T1 connection (robbed-bit) ... 11 Installation... 12 How to proceed with the installation... 12 Before you start ... 12 Installing Your Diva Server Adapter... -
Page 7: Introduction
Eicon Networks’ Diva Server adapters provide high-speed digital connections to support a variety of network applications. Important: All Diva Server adapters have been tested and found to comply with the Electromagnetic compatibility, Safety and Network connection regulations within North America and other major territories. Read the regulatory information in the section ‘Regulatory Information’... - Page 8 To install Acrobat Reader 4.0 under a Windows operating system: Insert your Diva Server Software Suite CD-ROM into your CD-ROM drive. The front end will automatically start. If the front end fails to start, double-click SETUP.EXE in the root folder on the CD-ROM. From the Welcome screen, click the ‘Bonus Software’...
-
Page 9: Ordering Your Isdn Pri Or T1 Line
Ordering Your ISDN PRI or T1 Line This chapter will assist you in ordering an ISDN PRI or a T1 line for your Diva Server T1/PRI adapter. It provides recommended settings for a number of the configuration settings on Diva Server T1/PRI adapters. You should specify these settings when you order your line from your service provider. -
Page 10: Provisioning An Isdn Pri Connection
Provisioning an ISDN PRI connection This section explains how to order an ISDN PRI line for your Diva Server T1/PRI adapter. What to order Specify the following requirements when you place your order: • 23 B-channels + 1 D-channel • D-channel on channel 24 (timeslot 24). Do not order NFAS (non-facility associated signaling service), which enables you to use channel 24 as a data-carrying B-channel. -
Page 11: Provisioning A Channelized T1 Connection (Robbed-Bit)
Provisioning a channelized T1 connection (robbed-bit) This section explains how to order a T1 line that uses robbed-bit signaling for your Diva Server T1/PRI adapter. What to order Specify the following when you place your order: • Switched T1 service for 56 kbps voice calls •... -
Page 12: Installation
• Diva Server adapter • cable(s) needed to connect your ISDN PRI or T1 line • Diva Server Software Suite CD-ROM • Diva Server Adapters Installation Guide You might be prompted to provide the CD-ROM for your operating system during the software installation. -
Page 13: Installing Your Diva Server Adapter
Installing Your Diva Server Adapter The installation procedure below applies for the following Plug&Play PRI adapters: • Diva Server T1/PRI PCI: Diva Server T1/PRI PCI, Diva Server T1/PRI-4M PCI, Diva Server T1/PRI-8M PCI, Diva Server T1/PRI-24M PCI • Diva Server Voice T1/PRI PCI: Diva Server Voice T1/PRI-4M PCI, Diva Server Voice T1/PRI-8M PCI, Diva Server Voice T1/PRI-24M PC Warning: PRI signals can have telephone network voltages (TNV). - Page 14 Note: If space does not permit the use of the retainer, simply remove it, and then insert the adapter. The retainer is only an installation aid and does not add functionality to the adapter. Warning: To avoid damaging your hardware, insert your Diva Server T1/PRI adapter only into a PCI slot.
- Page 15 Connect your ISDN PRI or T1 line as shown: 1. Take the cable included with the adapter. Server adapter 2. Plug one end into the adapter. If the Diva Server T1/PRI adapter in NT mode is connected to a PBX The Diva Server software enables you to configure Diva Server T1/PRI adapters as network termination (NT).
- Page 16 If the Diva Server T1/PRI adapter is run in back-to-back mode: The Diva Server software enables you to configure Diva Server T1/PRI adapters as network termination (NT). This means you can use two Diva Server adapters in back-to-back operation. When using Diva Server adapters back-to-back, configure one adapter as an NT and the other one as TE.
-
Page 17: Troubleshooting
Troubleshooting If you are having problems with your adapter or with the corresponding software, the following suggestions can help you diagnose and solve the problems. If these suggestions do not work for you, try the suggestions described in the online manual for the corresponding software, or those on the Help Web (see page 23). -
Page 18: Checking The Status Leds
Checking the status LEDs Diva Server T1/PRI and Diva Server Voice T1/PRI adapters have four LEDs, as shown: The table below describes the function of each LED: Color Status yellow blue green yellow green blue Description Normal operation. Remote site is experiencing synchronization problems (if a remote alarm/yellow alarm is detected). -
Page 19: Technical Specifications
Technical Specifications Diva Server T1/PRI Diva Server Voice T1/PRI Bus type PCI (3,3/5 V) 32 Bit RISC CPU, 180 MHz Memory 8 MB SDRAM Interrupt request levels Allocated by PCI BIOS. I/O base addresses (hex) Allocated by PCI BIOS. Shared memory range 8 MB DSPs Diva Server T1/PRI:... -
Page 20: Regulatory Information
Regulatory Information Regulatory Information for the USA WARNING. Changes or modifications to this unit not expressly approved by Eicon Networks Corporation could void the user's authority to operate the equipment. FCC Declaration of Conformity Eicon Networks Inc. 2155 Chenault Drive... -
Page 21: Regulatory Information For Canada
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Part 68 Notice This unit complies with Part 68 of the FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number. -
Page 22: Approvals
some cases, the company’s inside wiring associated with a single line individual service may be extended by means of certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Warning: For your safety, follow these steps before you remove the cover from your PC: 1. -
Page 23: Customer Services
Diva Server adapter or the corresponding software, try the suggestions listed on the Help Web before you call Customer Services. Comments If you wish to make comments about your Eicon Networks server adapter or the corresponding software, address them by E-mail to: divaserver@eicon.com. Customer Services...
