Digital Input 6

Parameter Default
X
DI6
(EC5)
Table 30: Digital Input 6
ECL-PTU-207 Preloaded Applications
Valid
Choices
0 UNUSED
1 AUX CONT NO
2 AUX CONT NC
3 CHG OVER HEAT
4 CHG OVER COOL
5 OCC SENSOR NO
6 OCC SENSOR NC
Tables of configuration codes
Description
DI5 is not used
Auxiliary contact is normally open
Auxiliary contact is normally closed
Changeover contact ( TRUE = Heat / FALSE = Cool)
Changeover contact (TRUE = Cool / FALSE = Heat)
Occupancy sensor is normally open
Occupancy sensor is normally closed
93
