Variables

DI5Config (ConstantEnum4)

This variable is used to configure hardware Input 5.
ID
Constant Enum 4

DI6Config (ConstantEnum5)

This variable is used to configure hardware Input 6.
ID
Constant Enum 5

SystemType (ConstantEnum6)

This variable is used to configure the system type of the installation.
ID
Constant Enum 6
10
Enumeration
0 = Unused: Hardware Input 5 is not used.
1 = AuxContactNO : Hardware Input 5 is used to connect a
normally open auxiliary contact.
2 = AuxContactNC : Hardware Input 5 is used to connect a
normally close auxiliary contact.
3 = ChangOverHtg : Hardware Input 5 is used to connect a
change-over input. (Contact close = Ceating mode)
4 = ChangOverClg : Hardware Input 5 is used to connect a
change-over input. (Contact close = Cooling mode)
5 = CondSensorNO : Hardware Input 5 is used to connect a
normally open condensation sensor. (Contact close = Alarm)
6 = CondSensorNC : Hardware Input 5 is used to connect a
normally close condensation sensor. (Contact close = Normal)
Enumeration
0 = Unused: Hardware Input 6 is not used.
1 = AuxContactNO : Hardware Input 6 is used to connect a
normally open auxiliary contact.
2 = AuxContactNC : Hardware Input 6 is used to connect a
normally close auxiliary contact.
3 = ChangOverHtg : Hardware Input 6 is used to connect a
change-over input. (Contact close = Ceating mode)
4 = ChangOverClg : Hardware Input 6 is used to connect a
change-over input. (Contact close = Cooling mode)
5 = OccSensorNO : Hardware Input 6 is to connect a normally
open occupancy sensor. configured to occupancy sensor
normaly open. (Contact close = occupied)
6 = OccSensorNC : Hardware Input 6 is to connect a normally
close occupancy sensor. configured to occupancy sensor
normaly open. (Contact close = unoccupied)
Enumeration
0 = Cool : 2 pipes cooling only
1 = CoolElectHeat : 2 pipes cooling only with electric heater
2 = heat : 2 pipes heating only
3 = CoolElectHeat : 2 pipes heating only with electric heater
4 = ChgOver: 2 pipes change-over
5 = ChgOverElectHeat: 2 pipes change-over with electric
heater
6 = CoolHeat: 4 pipes
7 = CoolHeatElectHeat: 4 pipes with electric heater
Default Value
Unused
Default Value
AuxContactNO
Default Value
CoolHeat
ECL-PTU-207 Preloaded Applications
