Tables of configuration codes

Tables of configuration codes

System Type

Parameter Default
TYPE
(EC6)
X

Fan Type

Parameter Default
FT
(nviFP39)
X
Table 20: Fan Ctrl Type

Fan Mode

Parameter Default
FAN (nviFP39) X
Table 21: Fan Mode
90
Valid
Choices
0 CL
1 CL-EH
2 HT
3 HT-EH
4 CO
5 CO-EH
6 CL-HT
7 CL-HT-EH
Valid
Choices
0 NONE
1 1 SP
2 2 SP
3 3 SP
4 ECM
Valid
Choices
0 ON
1 AUTO
2 SMART
3 AUTO HEAT
4 AUTO COOL
Description
2 Pipes cooling
2 Pipes cooling with electric heater
2 Pipes Heating
2 Pipes Heating with electric heater
2 Pipes Change Over
2 Pipes Change Over with electric heater
4 Pipes
4 Pipes with electric heater
Description
Fan control is not used
1-Speed fan
2-speed fan
3-speed fan
ECM motor (0-10V output)
Description
Fan is controlled between minimum speed and 100%
Fan control is based on terminal load
Fan control is based on terminal load when unoccupied,
and between minimum speed and 100% in other
occupancy modes.
Fan control is based on heaing load
Fan control is based on cooling load
ECL-PTU-207 Preloaded Applications
