Variables

nciDamperSettings (nviFP40)

This configuration property defines the different configuration of the air quality damper.
Field
outdoorCO2Offset
minPositionOcc
minPositionStby
maxPosition
Reserved1
Reserved2
Field Name
outdoorCO2Offset
minPositionOcc
minPositionStby
maxPosition
Reserved1
Reserved2
ID
nviFP40

nciHVACScaling (nviFP41)

This configuration property can be used to rescale the heating cooling load of the different equip-
ments.
Field
minCoolingValve
maxCoolingValve
minHeatingValve
maxHeatingValve
minElectHeater
maxElectHeater
Field Name
Default Value
Default Value
Default Value
Default Value
Default Value
Default Value
ID
nviFP41
26
Description
This configuration is used to calculate the effective Space CO2 setpoint when nviOutdoorCO2
is used.
This configuration is used to set the minimum damper position in occupied mode.
This configuration is used to set the minimum damper position in standby mode.
This configuration is used to set the maximum allowable damper position.
This configuration is not used in this program.
This configuration is not used in this program.
Min Value
100 ppm
0%
0%
0%
0%
0%
Units
UNVT_Damper_settings
Description
This configuration is used to select the cooling load value before starting the cooling valve
operation.
This configuration is used to select the cooling load value at which the cooling valve will be
at 100% operation.
This configuration is used to select the heating load value before starting the heating valve
operation.
This configuration is used to select the heating load value at which the heating valve will be
at 100% operation.
This configuration is used to select the heating load value before starting the electric heater
operation.
This configuration is used to select the heating load value at which the electric heater will be
at 100% operation.
Min Value
Default Value
Default Value
Default Value
Default Value
Default Value
Default Value
Units
UNVT_hvac_scaling
Max Value
2000 ppm
100%
100%
100%
100%
100%
Default Value
N/A
Min Value
Default Value
Default Value
Default Value
Default Value
Default Value
Default Value
ECL-PTU-207 Preloaded Applications
Default Value
600 ppm
10%
5%
100%
0%
0%
Default Value
Default Value
Default Value
Default Value
Default Value
Default Value
Default Value
Default Value
N/A
