Room Sensors

Allure EC-Smart-Vue and Allure EC-Smart-Comfort or EC-Smart-Air configuration parameters are
found in the Room Sensors subsection of the Hardware Configuration tab.
Figure 35: Room Sensor subsection
Parameter
EC-Smart-Vue CO Display enable
2
EC-Smart-Vue Display
EC-Smart-Vue Permissions
EC-Smart-Vue Units
Elevation
EC-Smart-Comfort/Air Sensor Sleep
Time
EC-Multi-Sensor Zone
ECL-PTU-207 Preloaded Applications
Description
Select whether the EC-Smart-Vue CO
Select what will be displayed on the home screen of the EC-Smart-Vue:
SpaceTemp: Displays the space temperature.
SpOffset: Displays the setpoint offset.
MidSetpoint: Displays the middle setpoint.
EffectSp: Displays the effective setpoint.
Defines how much access a user of the Allure EC-Smart-Vue has to the controller's
configuration parameters. The Allure EC-Smart-Vue access ranges from full access
to limited access or no access at all. Limited access allows setpoint adjustment only
or setpoint adjustment and airflow balancing.
Regardless of the access level of the Allure EC-Smart-Vue, the controller's
configuration parameters cannot be modified through the Allure EC-Smart-Vue
except after a password is entered.
Displays the units being used for the EC-Smart-Vue.
For accurate CO concentration levels, input geographic elevation here if elevation is
2
greater than 500ft (152m) above sea level. By default, the sensor is factory calibrated
to sea level.
Enter the amount of time before the sensor goes into standby mode.
Set the designated zone of the multi-sensor to match the remote.
Zone 0 (zero) indicates that the sensor is zone free and can be accessed by any
remote with any zone designation if it is within range.
Configuring the Preloaded Applications
Display is Enabled or Disabled.
