Variables

Enum Constants

ConfigOccSensor (ConstantEnum1)

This variable is used to configure the source of the motion detection sensor.
ID
Constant Enum 1

UI2Config (ConstantEnmu2)

This variable is used to configure the source of Hardware Input 2.
ID
Constant Enum 2

DI4Config (ConstantEnum3)

This variable is used to configure the hardware Input 4.
ID
Constant Enum 3
ECL-PTU-207 Preloaded Applications
Enumeration
0 = Unused: The system is not using any occupancy detection,
the final occupancy is equal to the occupancy received from
the BMS system, except if the device is a Slave device.
1 = Multi-Sensor : The system is using the EC-Multi-Sensor to
receive the occupancy detection information
2 = ComSensor : The system is using the EC-Smart-Vue to
receive the occupancy detection information
3 = DigitaInput : The system is using a Digital Input on DI6 to
receive the occupancy detection information.
4 = Auto/All : The system is using any occupancy sensor
connect to receive the motion detection information. If only one
sensor is occupied, the variable MotionSensor(MSV5) is set to
occupied.
Enumeration
0 = Unused : Hardware Input 2 is not used.
1 = Discharge Temp : Hardware Input 2 is used to connect the
Discharge Temperature sensor
2 = Return Temp: Hardware Input 2 is used to connect the
Return air Temperature sensor
3 = Return Temp: Hardware Input 2 is used to connect the
Water Temperature sensor
4 = SpOffset: Hardware Input 2 is used to connect the setpoint
offset of the EC-Sensor-SO.
Enumeration
0 = Unused: Hardware Input is not used.
1 = WindowContactNO : Hardware Input is used to connect a
normally opened window contact. (Contact close = Window
Open)
2 = WindowContactNC : Hardware Input is used to connect a
normaly close window contact. (Contact close = Window
Close)
Variables
Default Value
Auto/All
Default Value
SpOffset
Default Value
WindowContactNC
9
