DI4 - Input 4
Parameter Default
X
DI4 (EC3)
Table 13: Digital Input 4
DI5 - Input 5
Parameter Default
X
DI5
(EC4)
Table 14: Digital Input 5
DI6 - Input 6
ECL-PTU-207 Preloaded Applications
Valid
Choices
0 UNUSED
1 WINDOW NO
2 WINDOW NC
Valid
Choices
0 UNUSED
1 AUX CONT NO
2 AUX CONT NC
3 CHG OVER HEAT
4 CHG OVER COOL
5 COND SENSOR NO
6 COND SENSOR NC
Allure EC-Smart-Vue Screen-by-Screen Guide
Description
DI4 is not used
Window Contact is normally open
Window Contact is normally closed
Description
DI5 is not used
Auxiliary contact is normally open
Auxiliary contact is normally closed
Changeover contact ( TRUE = Heat / FALSE = Cool)
Changeover contact (TRUE = Cool / FALSE = Heat)
Condensation sensor is normally open
Condensation sensor is normally close
