CoolValveType (ConstantEnum7)

This variable is used to configure the Cooling or Change-Over Valve.
ID
Constant Enum 7
See IO assignement section for more details.

HeatValveType (ConstantEnum8)

This variable is used to configure the Heating Valve.
ID
Constant Enum 8
See IO assignement section for more details.

DamperCtrlType (ConstantEnum9)

This variable is used to configure the damper control type or disabled the damper control.
ID
Constant Enum 9
See IO assignement section for more details.
ECL-PTU-207 Preloaded Applications
Enumeration
0 = Unused: The valve is not used.
1 = 0-10V:: Only AO9 is used to control the valve.
2 = Thermal: DO5 is used to control the thermal valve and
AO9 to control the analog valve.
3 = On-Off: DO5 is used to control the digital valve and AO9 to
control the analog valve.
4 = Floating: DO5 and DO6 (DO5 = Open, DO6 = Close) are
used to control the Floating valve and AO9 to control the
analog valve.
Enumeration
0 = Unused: The valve is not used.
1 = 0-10V: Only AO10 is used to control the valve.
2 = Thermal: DO6 is used to control the thermal valve and
AO10 to control the analog valve.
3 = On-Off: DO6 is used to control the digital valve and AO10
to control the analog valve.
4 = Floating: DO5 and DO6 (DO5 = Open, DO6 = Close) are
used to control the Floating valve and AO10 to control the
analog valve.
Enumeration
0 = None: Damper Control is disabled.
1 = 0-10V : Damper used 0-10V signal type.
2 = 2-10V: Damper used 0-10V signal type
Variables
Default Value
Thermal
Default Value
Thermal
Default Value
0-10V
