A options: Fieldbuses

Available for the full product range
Fieldbus
A
VLT® PROFIBUS DP MCA 101
VLT® DeviceNet MCA 104
VLT® CANopen MCA 105
VLT® 3000 PROFIBUS Converter MCA 113
VLT® 5000 PROFIBUS Converter MCA 114
VLT® PROFINET MCA 120
VLT® EtherNet/IP MCA 121
VLT® Modbus TCP MCA 122
VLT® POWERLINK MCA 123
VLT® EtherCAT MCA 124
VLT® 5000 DeviceNet Converter MCA 194
PROFIBUS DP
Operating the AC drive via a fieldbus enables
you to reduce the cost of your system, commu-
nicate faster and more efficiently and benefit
from an easier user interface.
Other features:
„ Wide compatibility, a high level of availabi-
lity, support for all major PLC vendors, and
compatibility with future versions
„
Fast, efficient communication, transparent
installation, advanced diagnosis and para-
meterization and auto- configuration
of process data via GSD-file
„ Acyclic parameterization using PROFIBUS
DP-V1, PROFIdrive or Danfoss FC
(MCA101 only) profile state machines,
PROFIBUS DP-V1, Master Class 1 and 2
VLT® PROFIBUS DP MCA 101
Order code
130B1100 standard
130B1200 coated
DeviceNet
DeviceNet offers robust, efficient data han-
dling thanks to advanced Producer/Consumer
technology.
„
Support of ODVA's AC drive profile suppor-
ted via I/O instance 20/70 and 21/71 secures
compatibility to existing systems
„
Benefit from ODVA's strong conformance
testing policies, which ensure that products
are interoperable
„ Built-in web server
„ E-mail client for service notification
VLT® DeviceNet MCA 104
Order code
130B1102 standard
130B1202 coated
46
Danfoss Drives · DKDD.PB.302.A8.02 | Content |
CANopen
High flexibility and low cost are two of the
"cornerstones" for CANopen.
The CANopen option is fully equipped with
both high-priority access to control and status
of the drive (PDO Communication) and access
all parameters through acyclic data
(SDO Communication).
For interoperability, the option has
implemented the DSP402 AC drive Profile.
These features all guarantee standardized
handling, interoperability and low cost.
VLT® CANopen MCA 105
Order code
130B1103 standard
130B1205 coated
VLT® 3000 PROFIBUS
Converter
The VLT® PROFIBUS Converter MCA 113 is
a special version of the PROFIBUS options that
emulates the VLT® 3000 commands in the
VLT® AutomationDrive.
The VLT® 3000 can be replaced by the
VLT® AutomationDrive, or an existing system
can be expanded without costly change of the
PLC program.
VLT® 3000 PROFIBUS Converter MCA 113
Order code
130B1245 coated
VLT® 5000 PROFIBUS
Converter
The VLT® PROFIBUS Converter MCA 114 is
a special version of the PROFIBUS options that
emulates the VLT® 5000 commands in the
VLT® AutomationDrive.
The VLT® 5000 can be replaced by the
VLT® AutomationDrive, or an existing system
can be expanded without costly change of the
PLC program.
The option supports DPV1.
VLT® 5000 PROFIBUS Converter MCA 114
Order code
130B1246 coated
Typecode position
14
PROFINET
PROFINET uniquely combines the highest
performance with the highest degree of
openness. The option is designed so that many
of the features from the PROFIBUS can be
reused, minimizing user effort to migrate
PROFINET and securing the investment in
a PLC program.
„ Same PPO types as PROFIBUS for easy
migration to PROFINET
„ Support of MRP
„ Support of DP-V1 Diagnostic allows easy,
fast and standardized handling of warning
and fault information into the PLC,
improving bandwidth in the system
„ Implementation in accordance with
Conformance Class B
„ Built-in web server
„ E-mail client for service notification
VLT® PROFINET MCA 120
Order code
130B1135 standard, dual-port
130B1235 coated, dual-port
EtherNet/IP
Ethernet is the future standard for communica-
tion at the factory floor. EtherNet/IP is based on
the newest technology available for industrial
use and handles even the most demanding
requirements.
EtherNet/IP™ extends commercial off-the-shelf
Ethernet to the Common Industrial Protocol
(CIP™) – the same upper-layer protocol and
object model found in DeviceNet.
The option offers advanced features such as:
„ Built-in high performance switch enabling
line-topology, and eliminating the need for
external switches
„
DLR Ring
„ Advanced switch and diagnosis functions
„ Built-in web server
„
E-mail client for service notification
„ Unicast and Multicast communication
VLT® EtherNet/IP MCA 121
Order code
130B1119 standard, dual-port
130B1219 coated, dual-port
