VLT® Sine-wave Filter
MCC 101
„ VLT® Sine-wave Filters are positioned bet-
ween the AC drive and the motor to provide
a sinusoidal phase-to-phase motor voltage
„ Reduces motor insulation stress
„ Reduces acoustic noise from the motor
„ Reduces bearing currents (especially in large
motors)
„ Reduces losses in the motor
„
Prolongs service lifetime
„ VLT® FC series family look
Power range
3 x 200-500 V, 2.5-800 A
3 x 525-690 V, 4.5-660 A
Enclosure ratings
„ IP00 and IP20 wall-mounted enclosures
rated up to 75 A (500 V) or 45 A (690 V)
„
IP23 floor-mounted enclosures rated 115 A
(500 V) or 76 A (690 V) or more
„ IP54 both wall-mounted and floor-mounted
enclosures rated up to 4.5 A, 10 A,
22 A (690 V)
Ordering number
See relevant Design Guide
VLT® dU/dt Filter MCC 102
„
Reduces the dU/dt values on the motor
terminal phase-to-phase voltage
„ Positioned between the AC drive and the
motor to eliminate very fast voltage chan-
ges
„ The motor terminal phase-to-phase voltage
is still pulse shaped but its dU/dt values are
reduced
„ Reduces stress on the motor's insulation
and are recommended in applications with
older motors, aggressive environments or
frequent braking which cause increased DC
link voltage
„
VLT® FC series family look
Power range
3 x 200-690 V (up to 880 A)
Enclosure ratings
„ IP00 and IP20/IP23 enclosure in the entire
power range
„ IP54 enclosure available up to 177 A
Ordering number
See relevant Design Guide
VLT® Common Mode Filter
MCC 105
„ Positioned between the AC drive and the
motor
„ They are nano-crystalline cores that mitigate
high-frequency noise in the motor cable
(shielded or unshielded) and reduce bearing
currents in the motor
„ Extends motor bearing lifetime
„ Can be combined with dU/dt and sine-wave
filters
„ Reduces radiated emissions from the motor
cable
„
Reduces electromagnetic interference
„ Easy to install – no adjustments necessary
„ Oval shaped – allows mounting inside the
AC drive enclosure or motor terminal box
Power range
380-415 V AC (50 and 60 Hz)
440-480 V AC (60 Hz)
600 V AC (60 Hz)
500-690 V AC (50 Hz)
Ordering number
130B3257 Enclosure size A and B
130B7679 Enclosure size C1
130B3258 Enclosure size C2, C3 and C4
130B3259 Enclosure size D
130B3260 Enclosure size E and F
VLT® Advanced Harmonic
Filter AHF 005 and AHF 010
„ Optimized harmonic performance for
VLT® drives rated up to 250 kW
„ A patented technique reduces THD levels in
the mains network to less than 5-10%
„ Perfect match for industrial automation,
highly dynamic applications and safety
installations
Power range
380-415 V AC (50 and 60 Hz)
440-480 V AC (60 Hz)
600 V AC (60 Hz)
500-690 V AC (50 Hz)
Enclosure ratings
„
IP20
(An IP21/NEMA 1 upgrade kit is available)
„ IP00
(Forced cooling is required. There is no fan
in the IP00 unit. Separate cooling measures
must be implemented in the cabinet as part
of the installation)
Ordering number
See relevant Design Guide
VLT® Brake Resistor MCE 101
„ Energy generated during braking is
absorbed by the resistors, protecting
electrical components from heating up
„ Optimized for the FC-series and general
versions for horizontal and vertical motion
are available
„ Built-in thermo switch
„ Versions for vertical and horizontal
mounting
„ A selection of the vertically mounted units
are UL-recognized
Power range
Precision electrical match to each individual
VLT® drive power size
Enclosure ratings:
„ IP20
„
IP21
„ IP54
„ IP65
Ordering number
See relevant Design Guide
VLT® Line Reactor MCC 103
„ Ensures current balance in load-sharing ap-
plications, where the DC-side of the rectifier
of multiple drives is connected together
„ UL-recognized for applications using load
sharing
„
When planning load-sharing applications,
pay special attention to different enclosure
type combinations and inrush concepts
„ For technical advice regarding load-sharing
applications, contact Danfoss application
support
„ Compatible with VLT® AutomationDrive
50 Hz or 60 Hz mains supply
Ordering number
See relevant Design Guide
