Technical data

Basic unit without extensions
Main supply (L1, L2, L3)
Supply voltage
Supply frequency
Displacement power factor
(cos ф) near unity
Switching on input supply
L1, L2, L3
Output data (T1, T2, T3)
Output voltage
Output frequency
Switching on output
Ramp times
Digital inputs
Programmable digital inputs
Changeable to digital output
Logic
Voltage level
Maximum voltage on input
Input resistance, Ri
Scan interval
* Two of the inputs can be used as digital outputs
Analog inputs
Analog inputs
Modes
Voltage level
Current level
Accuracy of analog inputs
Pulse inputs
Programmable pulse inputs
Voltage level
Pulse input accuracy
(0.1-1 kHz)
* Two of the digital inputs can be used for pulse inputs.
Digital outputs
Programmable
digital/pulse outputs
Voltage level at
digital/frequency output
Max. output current
(sink or source)
Maximum output frequency
Accuracy on frequency output
Analog outputs
Programmable
analog outputs
Current range at
analog output
Max. load to common at
analog output (clamp 30)
Accuracy on analog output
Agency approvals
200-240 V AC
380-500 V AC
525-600 V AC
525-690 V AC
50/60 Hz
> 0.98
1-2 times/min.
0-100% of supply voltage
0-590 Hz
Unlimited
0.01-3600 s
6*
2 (terminal 27, 29)
PNP or NPN
0-24 V DC
28 V DC
Approx. 4 kΩ
5 ms
2
Voltage or current
0 to +10 V (scaleable)
0/4 to 20 mA (scaleable)
Max. error: 0.5% of full scale
2*
0-24 V DC (PNP positive logic)
Max. error: 0.1% of full scale
2
0-24 V DC
40 mA
0-32 kHz
Max. error: 0.1% of full scale
1
0/4-20 mA
500 Ω
Max. error: 0.5 % of full scale
Control card
USB interface
USB plug
RS485 interface
Max. load (10 V)
Max. load (24 V)
Relay outputs
Programmable relay outputs
Max. terminal load (AC)
on 1-3 (NC), 1-2 (NO),
4-6 (NC) power card
Max. terminal load (AC -1) on
4-5 (NO) power card
Min. terminal load on
1-3 (NC), 1-2 (NO),
4-6 (NC), 4-5 (NO)
power card
Surroundings/external
Ingress protection class
Vibration test
Max. relative humidity
Ambient temperature
Galvanic isolation of all
Aggressive environment
Ambient temperature
– Operating temperature range is -25 °C to 50 °C without derating
Max 55 °C with derating
Fieldbus communication
Standard built-in:
FC Protocol
N2 Metasys
FLN Apogee
Modbus RTU
Protection mode for longest possible up-time
– Electronic motor thermal protection against overload
– Protection against overtemperature
– The AC drive is protected against short circuits
on motor terminals R, S, T
– The AC drive is protected against ground faults
on motor terminals U, V, W
– Protection against mains phase loss
– Real-Time Clock with battery backup
– Advanced data logging using real-time stamps
– Predictive maintenance
– Preventive maintenance
– D-option VLT® Real-time Clock Option MCB 117
| Content | Danfoss Drives · DKDD.PB.302.A8.02
1.1 (Full Speed)
Type "B"
Up to 115 kBaud
15 mA
200 mA
2
240 V AC, 2 A
400 V AC, 2 A
24 V DC 10 mA, 24 V AC 20 mA
IP: 00/20/21/54/55/66
UL Type: Chassis/1/12/3R/4X
0.7 g
5-95% (IEC 721-3-3); Class 3K3
(non-condensing) during operation
Max. 50 °C without derating
I/O supplies according to PELV
Designed for 3C3 (IEC 60721-3-3)
Optional:
VLT® PROFIBUS DP V1 MCA 101
VLT® DeviceNet MCA 104
VLT® CANopen MCA 105
VLT® 3000 PROFIBUS Converter MCA 113
VLT® 5000 PROFIBUS Converter MCA 114
VLT® PROFINET MCA 120
VLT® EtherNet/IP MCA 121
VLT® Modbus TCP MCA 122
VLT® POWERLINK MCA 123
VLT® EtherCAT MCA 124
VLT® 5000 DeviceNet Converter MCA 194
