Danfoss VLT AutomationDrive FC 300 Series Selection Manual page 11

690 V
The 690 V versions of VLT®
AutomationDrive FC 302 units for
the power range from 1.1 kW up
to 1400 kW can control motors
down to 0.37 kW without step-
down transformer. This enables you
to choose from a broad variety of
compact, reliable and efficient drives
for demanding production facilities
operating from 690 V mains networks.
Reduce costs with
compact drives
A compact design and efficient heat
management enable the drives to take
up less space in control rooms and
panels, thereby reducing initial costs.
Compact dimensions are also an
advantage in applications where
drive space is restricted, making it
possible for designers to develop
smaller applications without being
forced to compromise on protection
and grid quality. For example, VLT®
Choose the adequate performance level
Special needs require special features and performance
Power range [kW] 200-240 V
Power range [kW] 380-(480) 500 V
Power range [kW] 525-600 V
Power range [kW] 525-690 V
Flux vector control
Cable length – screened/unscreened
Permanent magnet motor operation
(w/wo feedback)
Safety function Safe Torque Off (STO – EN 61800-5-2)
Scan interval/response time ms
Output frequency (OL)
Max load (24 V DC) for analog output and
control card [mA]
Programmable digital input
Programmable digital output changeable
Programmable relay output
* For frequency up to 1000 Hz please contact your local Danfoss partner.
AutomationDrive FC 302 in a D or E
enclosure size is 25-68% smaller than
equivalent drives.
Despite the compact dimensions,
all units are nevertheless equipped
with integrated DC link chokes and
EMC filters, which help to reduce grid
pollution and reduce cost and efforts
for external EMC components and
wiring.
The IP20 version is optimized for
side-by-side mounting in cabinets to
50 °C without derating and features
covered power terminals to prevent
accidental contact. The AC drive can
also be ordered with an optional brake
chopper in the same package size.
Control and power cables are fed in
separately at the bottom.
The AC drives combine a flexible
system architecture that allows them
to be adapted to specific applications,
with a uniform user interface across all
FC 301 FC 302
0.25-37 0.25-37
0.37-75 (480 V) 0.37-800 (500 V)
– 0.75-75
– 1.1-1400
–
25/50m (A1 only),
150/300 m
50/75m
–
Optional (A1 only)
5
0-590 Hz,
0.2-590 Hz
(600-1000 Hz)*
130
5 (4)
1
1
power classes. This allows you to adapt
the drive to the exact needs of your
specific application. As a result, project
work and costs are subsequently
reduced. The easy-to-use interface
reduces training requirements. The
integrated SmartStart guides users
quickly and efficiently through the set-
up process, resulting in fewer faults due
to configuration and parameterization
errors.
Power range
200-240 V
High overload
208 V ........................1.8-143 A I
230 V .........................1.8-170 A I
Normal overload
208 V ........................ 1.8-170 A I
230 V .........................1.8-170 A I
380-500 V
High overload
400 V ..................1.3-1460 A I
460 V ...................1.2-1380 A I
Normal overload
400 V ................1.3-1720 A I
460 V ...................1.2-1530 A I
525-600 V
High overload
575 V .............................1.7-100 A I
Normal overload
575 V .............................1.7-131 A I
525-690 V
„
High overload
575 V ...................1.6-1260 A I
690 V ...................1.6-1260 A I
„
„
Normal overload
1
575 V ...................1.6-1415 A I
690 V ...................1.6-1415 A I
200
Ingress protection ratings
6 (4)
IEC: IP00, IP20, IP21, IP54, IP55, IP66
2
UL: Chassis, Type 1, Type 12, Type 4X
2
| Content | Danfoss Drives · DKDD.PB.302.A8.02
, 0.25-37 kW,
N
, 0.34-50 Hp
N
, 0.25-45 kW
N
, 0.34-60 Hp
N
, 0.37-800 kW,
N
, 0.5-1200 Hp
N
, 0.37-1000 kW
N
, 0.5-1350 Hp
N
, 1-100 Hp
N
, 1-120 Hp
N
, 1.5-1350 Hp
N
, 1.1-1200 kW
N
, 1.1-1550 Hp
N
, 1.1-1400 kW
N
