Common Motor Terminals
The common motor terminal option provides
the bus bars and hardware required to connect
the motor terminals from the paralleled
inverters to a single terminal (per phase) to ac-
commodate the installation of the motor-side
top entry kit.
This option is also recommended to connect
the output of a drive to an output filter or out-
put contactor. The common motor terminals
eliminate the need for equal cable lengths
from each inverter to the common point of the
output filter (or motor).
24 V DC supply
„ 5 A, 120 W, 24 V DC
„
Protected against output overcurrent, over-
load, short circuits, and overtemperature
„ For powering customer-supplied accessory
devices such as sensors, PLC I/O, contactors,
temperature probes, indicator lights and/or
other electronic hardware
„ Diagnostics include a dry DC-ok contact, a
green DC-ok LED and a red overload LED
„ Version with RTC available
External temperature
monitoring
Designed for monitoring temperatures of
external system components, such as the mo-
tor windings and/or bearings. Includes eight
universal input modules plus two dedicated
thermistor input modules. All ten modules
are integrated into the drive's Safe Torque Off
circuit and can be monitored via a fieldbus

Loose kits for enclosure sizes D, E and F

Kit
NEMA 3R outdoor weather shield
USB in the door kit
Enclosure size F top entry kit motor cables
Enclosure size F top entry kit mains cables
Common motor terminal kits
Adapter plate
Back-channel duct kit
NEMA 3R Rittal and welded enclosures
Back-channel cooling kits for non-Rittal enclosures
Back-channel cooling kit (in-bottom/out-top)
Back-channel cooling kit (in-back/out-back)
Pedestal kit with in-back/out-back cooling
Pedestal kit
Top entry of fieldbus cables
LCP Remote Mounting Kit
Ground bar kit
NEMA 3R outdoor
weather shield
Designed to be mounted over the VLT® drive
to protect from direct sun, snow and falling
debris. Drives used with this shield must be
ordered from the factory as "NEMA 3R Ready".
This is an enclosure option in the type code
– E5S.
Ordering number
D1h ........................................................................... 176F6302
D2h ........................................................................... 176F6303
54
Danfoss Drives · DKDD.PB.302.A8.02 | Content |
network, which requires the purchase of a sep-
arate module/bus coupler. A Safe Torque Off
brake option must be ordered when selecting
external temperature monitoring.
Universal inputs (5)
Signal types:
„
RTD inputs (including Pt100), 3-wire or
4-wire
„ Thermocouple
„ Analog current or analog voltage
Additional features:
„ One universal output, configurable for
analog voltage or analog current
„ Two output relays (N.O.)
„ Dual-line LC display and LED diagnostics
„
Sensor lead wire break, short circuit and
incorrect polarity detection
„ Interface set-up software
„ If 3 PTC are required, an MCB 112 control
card option must be added.
Additional external temperature monitors:
„
This option is available in case you need
more than the MCB 114 and MCB 112
provides.
VLT® Control Panel LCP 101
(Numeric)
„ Status messages
„ Quick menu for easy commissioning
„
Parameter setting and adjusting
„ Hand-operated start/stop function or
selection of Automatic mode
„
Reset function
Ordering number
130B1124
USB in the door kit
Available for all enclosure sizes, this USB
extension cord kit allows access to the drive
controls via laptop computer without opening
the drive.
The kits can only be applied to drives manu-
factured after a certain date. Drives built prior
to these dates do not have the provisions to
accommodate the kits. Reference the following
table to determine which drives the kits can be
applied to.
Ordering number
Enclosure sizes D ..............................................130B1155
Enclosure sizes E ...............................................130B1156
Enclosure sizes F ............................................... 176F1784
VLT® Control Panel LCP 102
(Graphical)
„ Multi-language display
„ Quick menu for easy commissioning
„ Full parameter back-up and copy function
„
Alarm logging
„ Info key explains the function of the
selected item on display
„
Hand-operated start/stop or selection of
Automatic mode
„ Reset function
„ Trend graphing
Ordering number
130B1107
VLT® Wireless
Communication Panel
LCP 103
„ Full access to the drive
„ Real-time error messages
„ PUSH notifications for alarms/warnings
„ Safe and secure WPA2 encryption
„ Intuitive parameter functionalities
„
Live graphs for monitoring and fine tuning
„ Multi-language support
„ Upload or download parameter file to the
built-in memory or to your smartphone
Ordering number
134B0460
Available for following enclosure sizes
D1h, D2h
D1h, D2h, D3h, D4h, D5h, D6h,
D7h, D8h, E1h, E2h, E3h, E4h, F
F
F
F1/F3, F2/F4
D1h, D2h, D3h, D4h
D1h, D2h, D3h, D4h, E3h, E4h
D3h, D4h
D3h, D4h
D1h, D2h, D3h, D4h, E3h, E4h
D1h, D2h, D3h, D4h, E3h, E4h, F
D1h, D2h
D1h, D2h, D5h, D6h, D7h, D8h
D3, D4, D1h-D8h
Available for the full product range
E1h, E2h
Enclosure size F top entry kit
motor cables
To use this kit, the drive must be ordered with
the common motor terminal option. The
kit includes everything to install a top entry
cabinet on the motor side (right side) of an F
size enclosure.
Ordering number
F1/F3, 400 mm ................................................... 176F1838
F1/F3, 600 mm ....................................................176F1839
F2/F4 400 mm ....................................................176F1840
F2/F4, 600 mm ....................................................176F1841
F8, F9, F10, F11, F12, F13 ................. Contact factory
