Electrical data – D, E and F enclosures
[T5] 3 x 380-500 V AC – high overload
Output current
Type
code
(3 x 380-440 V)
Inter. I
FC-302 Con. I
(60 s)
N
N90K 177 266
N110 212 318
N132 260 390
N160 315 473
N200 395 593
N250 480 720
N315 600 900
N355 658 987
N400 695 1043
N450 800 1200
N500
880 1320
P450 800 1200
P500 880 1320
P560 990 1485
P630 1120 1680
P710 1260 1890
P800 1460 2190
[T5] 3 x 380-500 V AC – normal overload
Output current
Type
code
(3 x 380-440 V)
Inter. I
FC-302 Con. I
(60 s)
N
N90K 212 233
N110 260 286
N132 315 347
N160 395 435
N200 480 528
N250 588 647
N315 658 724
N355 745 820
N400 800 880
N450 880 968
N500 990 1089
P450 880 968
P500
990 1089
P560 1120 1232
P630 1260 1386
P710 1460 1606
P800 1720 1892
36
Danfoss Drives · DKDD.PB.302.A8.02 | Content |
High overload (150% 1 min/10 min)
(3 x 441-500 V)
Inter. I
Con. I kW @ 400 V
MAX MAX
(60 s)
N
160 240
190 285
240 360
302 453
361 542
443 665
540 810
590 885
678 1017
730 1095
780 1170
730 1095
780 1170
890 1335
1050 1575
1160 1740
1380 2070
Normal overload (110% 1 min/10 min)
(3 x 441-500 V)
Inter. I
Con. I kW @ 400 V
MAX MAX
(60 s)
N
190 209
240 264
302 332
361 397
443 487
535 588
590 649
678 746
730 803
780 858
890 979
780 858
890 979
1050 1155
1160 1276
1380 1518
1530 1683
Conti-
Typical shaft nuous
output power input
current
Hp @ 460 V
90 125
110 150
132 200
160 250
200 300
250 350
315 450
355 500
400 550
450 600
500 650
450 600
500 650
560 750
630 900
710 1000
800 1200
Conti-
Typical shaft nuous
output power input
current
Hp @ 460 V
110 150
132 200
160 250
200 300
250 350
315 450
355 500
400 600
450 600
500 650
560 750
500 650
560 750
630 900
710 1000
800 1200
1000 1350
Enclosure size
Esti- Protection rating [IEC/UL]
mated
power
IP20
loss
[A] [W] Chassis
171 2031 D3h
204 2289 D3h
251 2923 D3h
304 3093 D4h
381 4039 D4h
463 5005 D4h
578 6178 E3h
634 6851 E3h
670 7297 E3h
771 8352 E4h
E4h
848 9449
779 9031 –
857 10146 –
964 10649 –
1090 12490 –
1227 14244 –
1422 15466 –
Enclosure size
Esti- Protection rating [IEC/UL]
mated
power
IP20
loss
[A] [W] Chassis
204 2559 D3h
251 2954 D3h
304 3770 D3h
381 4116 D4h
463 5137 D4h
567 6674 D4h
634 6928 E3h
718 8036 E3h
771 8783 E3h
848 9473 E4h
954 11102 E4h
857 10162 –
–
964 11822
1090 12512 –
1227 14674 –
1422 17293 –
1675 19278 –
IP21 IP54
Type 1 Type 12
D1h/D5h/D6h
D1h/D5h/D6h
D1h/D5h/D6h
D2h/D7h/D8h
D2h/D7h/D8h
D2h/D7h/D8h
E1h E1h
E1h E1h
E1h E1h
E2h E2h
E2h E2h
F1/F3 F1/F3
F1/F3 F1/F3
F1/F3 F1/F3
F1/F3 F1/F3
F2/F4 F2/F4
F2/F4 F2/F4
IP21 IP54
Type 1 Type 12
D1h/D5h/D6h
D1h/D5h/D6h
D1h/D5h/D6h
D2h/D7h/D8h
D2h/D7h/D8h
D2h/D7h/D8h
E1h E1h
E1h E1h
E1h E1h
E2h E2h
E2h E2h
F1/F3 F1/F3
F1/F3 F1/F3
F1/F3 F1/F3
F1/F3 F1/F3
F2/F4 F2/F4
F2/F4 F2/F4
