Electrical data – A, B, and C enclosures
[T2] 3 x 200-240 V AC – high overload
Type Output current
code (3 x 200-240 V)
FC-302 Con. I
N
PK25 1.8
PK37 2.4
PK55 3.5
PK75 4.6
P1K1 6.6
P1K5
7.5
P2K2 10.6
P3K0 12.5
P3K7 16.7
P5K5 24.2
P7K5 30.8
P11K 46.2
P15K
59.4
P18K 74.8
P22K 88
P30K 115
P37K 143
*A1 enclosure is only available as FC 301
[T2] 3 x 200-240 V AC – normal overload
Type Output current
code (3 x 200-240 V)
FC-302 Con. I
N
PK25 1.8
PK37 2.4
PK55 3.5
PK75 4.6
P1K1 6.6
P1K5 7.5
P2K2 10.6
P3K0 12.5
P3K7 16.7
P5K5 30.8
P7K5 46.2
P11K 59.4
P15K
74.8
P18K 88
P22K 115
P30K 143
P37K 170
*A1 enclosure is only available as FC 301
30
Danfoss Drives · DKDD.PB.302.A8.02 | Content |
High overload (160% 1 min/10 min)
Typical shaft
output power
Inter. I kW @ Hp @
MAX
(60 s) 208 V 230 V
2.9 0.25 0.34
3.8 0.37 0.5
5.6 0.55 0.75
7.4 0.75 1
10.6 1.1 1.5
12 1.5 2
17 2.2 3
20 3 4
26.7 3.7 5
38.7 5.5 7.5
49.3 7.5 10
73.9 11 15
89.1 15 20
112 18.5 25
132 22 30
173 30 40
215 37 50
Normal overload (110% 1 min/10 min)
Typical shaft
output power
Inter. I kW @ Hp @
MAX
(60 s) 208 V 230V
2.9 0.25 0.34
3.8 0.37 0.5
5.6 0.55 0.75
7.4 0.75 1
10.6 1.1 1.5
12 1.5 2
17 2.2 3
20 3 4
26.7 3.7 5
33.9 7.5 10
50.8 11 15
65.3 15 20
82.3 18.5 25
96.8 22 30
127 30 40
157 37 50
187 45 60
Conti nuous Estimated
input current power loss
[A] [W]
2.6 21
3.5 29
5.1 42
6.6 54
9.4 63
10.9 82
15.2 116
18.1 155
24 185
35.2 239
44.8 371
67.2 463
81 624
102 740
120 874
156 1143
195 1400
Conti nuous Estimated
input current power loss
[A] [W]
2.6 21
3.5 29
5.1 42
6.6 54
9.4 63
10.9 82
15.2 116
18.1 155
24 185
30.8 310
46.2 514
59.4 602
74.8 737
88 845
114 1140
143 1353
169 1636
Enclosure size
Protection rating [IEC/UL]
IP20/21 IP21 IP55
Chassis Type 1 Type 12
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A2 A2 A4/A5
A3 A3 A5
A3 A3 A5
B3 B1 B1
B3 B1 B1
B4 B2 B2
B4 C1 C1
C3 C1 C1
C3 C1 C1
C4 C2 C2
C4 C2 C2
Enclosure size
Protection rating [IEC/UL]
IP20/21 IP21 IP55
Chassis Type 1 Type 12
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A2 A2 A4/A5
A3 A3 A5
A3 A3 A5
B3 B1 B1
B3 B1 B1
B4 B2 B2
B4 C1 C1
C3 C1 C1
C3 C1 C1
C4 C2 C2
C4 C2 C2
IP66
Type 4X
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
B1
B1
B2
C1
C1
C1
C2
C2
IP66
Type 4X
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
B1
B1
B2
C1
C1
C1
C2
C2
