[T5] 3 x 380-500 V AC – high overload
Output current
Type
code
(3 x 380-440 V)
Inter. I
FC-302 Con. I
MAX
(60 s)
N
PK37 1.3 2.1
PK55 1.8 2.9
PK75 2.4 3.8
P1K1 3 4.8
P1K5 4.1 6.6
P2K2 5.6 9
P3K0 7.2 11.5
P4K0 10 16
P5K5 13 20.8
P7K5 16 25.6
P11K
24 38.4
P15K 32 51.2
P18K 37.5 60
P22K 44 70.4
P30K 61 91.5
P37K 73 110
P45K 90 135
P55K
106 159
P75K 147 221
*A1 enclosure is only available as FC 301
[ T5] 3 x 380-500 V AC – normal overload
Output current
Type
code
(3 x 380-440 V)
Inter. I
FC-302 Con. I
MAX
(60 s)
N
PK37 1.3 2.1
PK55 1.8 2.9
PK75 2.4 3.8
P1K1 3 4.8
P1K5 4.1 6.6
P2K2 5.6 9
P3K0 7.2 11.5
P4K0 10 16
P5K5 13 20.8
P7K5 16 25.6
P11K 32 35.2
P15K 37.5 41.3
P18K 44 48.4
P22K 61 67.1
P30K 73 80.3
P37K 90 99
P45K 106 117
P55K
147 162
P75K 177 195
*A1 enclosure is only available as FC 301
High overload (160% 1 min/10 min)
Typical shaft
output power
(3 x 441-500 V)
Inter. I kW @
Con. I
MAX
(60 s) 400 V
N
1.2 1.9 0.37
1.6 2.6 0.55
2.1 3.4 0.75
2.7 4.3 1.1
3.4 5.4 1.5
4.8 7.7 2.2
6.3 10.1 3
8.2 13.1 4
11 17.6 5.5
14.5 23.2 7.5
21 33.6 11
27 43.2 15
34 54.4 18.5
40 64 22
52 78 30
65 97.5 37
80 120 45
105 158 55
130 195 75
Normal overload (110% 1 min/10 min)
Typical shaft
output power
(3 x 441-500 V)
Inter. I kW @
Con. I
MAX
(60 s) 400 V
N
1.2 1.9 0.37
1.6 2.6 0.55
2.1 3.4 0.75
2.7 4.3 1.1
3.4 5.4 1.5
4.8 7.7 2.2
6.3 10.1 3
8.2 13.1 4
11 17.6 5.5
14.5 23.2 7.5
27 29.7 15
34 37.4 18.5
40 44 22
52 57.2 30
65 71.5 37
80 88 45
105 116 55
130 143 75
160 176 90
Conti- Esti-
nuous mated
input power
current loss
Hp @
[A] [W]
460 V
0.5 1.9 35
0.75 2.6 42
1 3.5 46
1.5 4.3 58
2 5.9 62
3 8 88
4 10.4 116
5 14.4 124
7.5 18.7 187
10 23 255
15 35.2 291
20 46.4 379
25 54.4 444
30 64 547
40 82.5 570
50 99 697
60 123 891
75 144 1022
100 200 1232
Conti- Esti-
nuous mated
input power
current loss
Hp @
[A] [W]
460 V
0.5 1.9 35
0.75 2.6 42
1 3.5 46
1.5 4.3 58
2 5.9 62
3 8 88
4 10.4 116
5 14.4 124
7.5 18.7 187
10 23 255
20 31.9 392
25 37.4 465
30 44 525
40 60.5 739
50 72.6 698
60 90.2 843
75 106 1083
100 146 1384
125 177 1474
| Content | Danfoss Drives · DKDD.PB.302.A8.02
Enclosure size
Protection rating [IEC/UL]
IP20/21 IP21 IP55
Chassis Type 1 Type 12
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A2 A2 A4/A5
A2 A2 A4/A5
A2 A2 A4/A5
A3 A3 A5
A3 A3 A5
B3 B1 B1
B3 B1 B1
B4 B2 B2
B4 B2 B2
B4 C1 C1
C3 C1 C1
C3 C1 C1
C4 C2 C2
C4 C2 C2
Enclosure size
Protection rating [IEC/UL]
IP20/21 IP21 IP55
Chassis Type 1 Type 12
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A1*/A2 A2 A4/A5
A2 A2 A4/A5
A2 A2 A4/A5
A2 A2 A4/A5
A3 A3 A5
A3 A3 A5
B3 B1 B1
B3 B1 B1
B4 B2 B2
B4 B2 B2
B4 C1 C1
C3 C1 C1
C3 C1 C1
C4 C2 C2
C4 C2 C2
IP66
Type 4X
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
B1
B1
B2
B2
C1
C1
C1
C2
C2
IP66
Type 4X
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
B1
B1
B2
B2
C1
C1
C1
C2
C2
