Ordering typecode for D, E and F enclosures

[1] [2]
FC- – –
[1] Application (character 4-6)
302 VLT® AutomationDrive FC 302
[2] Power size (character 7-10)
N75K 75 kW / 100 Hp
N90K 90 kW / 125 Hp
N110 110 kW / 150 Hp
N132 132 kW / 200 Hp
N160 160 kW / 250 Hp
N200 200 kW / 300 Hp
N250 250 kW / 350 Hp
N315 315 kW / 450 Hp
P315 315 kW / 450 Hp
N355 355 kW / 500 Hp
P355 355 kW / 500 Hp
N400 400 kW / 550 Hp
P400 400 kW / 550 Hp
N450 450 kW / 600 Hp
P450 450 kW / 600 Hp
N500 500 kW / 650 Hp
P500 500 kW / 650 Hp
N560 560 kW / 750 Hp
P560 560 kW / 750 Hp
N630 630 kW / 900 Hp
P630 630 kW / 900 Hp
N710 710 kW / 1000 Hp
P710 710 kW / 1000 Hp
N800 800 kW / 1200 Hp
P800 800 kW / 1200 Hp
P900 900 kW / 1250 Hp
P1M0 1.0 MW / 1350 Hp
P1M2 1.2 MW / 1600 Hp
P1M4 1.4 MW / 1900 Hp
[3] AC mains voltage (character 11-12)
T5 3 x 380-500 V AC
3 x 525-690 V AC
T7
690 V kW. See manuals for 575 V Hp
[4] IP/UL protection ratings (character 13-15)
IP00 / Chassis enclosures
E00 IP00 / Chassis (D4, E2 enclosures)
C00 IP00 / Chassis – Stainless steel back channel
IP20 / Chassis enclosures
E21 IP21 / Type 1
E2M IP21 / Type 1 + mains shield
E2D IP21 / Type 1 (D1h, D5h, D6h enclosures)
H21 IP21 / Type 1 + space heater
C21 IP21 / Type 1 – Stainless steel back channel
IP21 / Type 1 – Stainless steel back channel
C2M
+ mains shield
IP21 / Type 1 – Stainless steel back channel
C2D
(D1h, D5h, D6h enclosures)
IP21 / Type 1 – Stainless steel back channel
C2H
+ space heater
42
Danfoss Drives · DKDD.PB.302.A8.02 | Content |
[3] [4] [5] [6]
– – –
IP21 / Type 1 + cabinet light
L2A
+ 115 V power outlet
IP21 / Type 1 + cabinet light
L2X
+ 230 V power outlet
IP21 / Type 1 + space heater + cabinet light
R2A
+ 115 V power outlet
IP21 / Type 1 + space heater + cabinet light
R2X
+ 230 V power outlet
IP21 / Type 1 – Stainless steel back channel
C2E
+ Cooling out the back
IP21 / Type 1 – Stainless steel back channel
C2J
+ cooling out the back + space heater
E2E IP21 / Type 1 – cooling out the back
IP21 / Type 1 – cooling out the back
E2J
+ space heater
IP54 / UL Type 12 enclosures
E54 IP54 / Type 12
E5D IP54 / Type 12 (D1, D1h, D5h, D6h frames)
E5M IP54 / Type 12 + mains shield
IP54 / Type 12, NEMA 3R ready – Stainless steel
E5S
screws + space heater (D1h, D2h frames)
H54 IP54 / Type 12 + space heater + thermostat
C54 IP54 / Type 12 – Stainless steel back channel
IP54 / Type 12 – Stainless steel back channel
C5M
+ mains shield
IP54 / Type 12 – Stainless steel back channel
C5H
+ space heater
IP54 / Type 12 + cabinet light
L5A
+ 115 V power outlet
IP54 / Type 12 + cabinet light
L5X
+ 230 V power outlet
IP54 / Type 12 + space heater + cabinet light
R5A
+ 115 V power outlet
IP54 / Type 12 + space heater + cabinet light
R5X
+ 230 V power outlet
E5E IP54 / Type 12 – cooling out the back
IP54 / Type 12 – Stainless steel back channel
C5E
+ cooling out the back
IP54 / Type 12 – Stainless steel back channel
C5J
+ cooling out the back + space heater
IP54 / Type 12 – cooling out the back
E5J
+ space heater
IP66 / UL Type 4X enclosures
E66 IP66 / Type 4X
Y66 IP66 / Type 4X + backplate (no C-options)
Z66 IP66 / Type 4X (no C-options)
[5] RFI filter, terminal and monitoring options
– EN/IEC 61800-3 (character 16-17)
H2 RFI filter, Class A2 (C3)
RFI filter, Class A1 (C2)
H4
(Enclosure sizes D and F only)
RFI filter, Class A2 (C3)
H5
Marine ruggedized
IRM for IT mains with Class A2 RFI
HG
(Enclosure sizes F1, F2, F3, F4)
[7] [8] [9] [10] [11] [12]
– – – – – –
[13] [14] [15] [16]
– – – – CX –
RCD for TN/TT mains with Class A2 RFI
HE
(Enclosure sizes F1, F2, F3, F4)
HX No RFI filter
RCD for TN/TT mains and Class A1 RFI
HF
(Enclosure sizes F1, F2, F3, F4)
IRM for IT mains and Class A1 RFI
HH
(Enclosure sizes F1, F2, F3, F4)
VLT® Low Harmonic Drive
VLT® Low Harmonic Drive, active filter
N2
based with Class A2 RFI
VLT® Low Harmonic Drive, active filter
N4
based with Class A1 RFI
VLT® 12-Pulse, encl. sizes F8, F9, F10, F11, F12, F13
B2 12-Pulse with Class A2 RFI
B4 12-Pulse with Class A1 RFI
BE 12-Pulse with RCD / A2 RFI
BF 12-Pulse with RCD / A1 RFI
BG 12-Pulse with IRM / A2 RFI
BH 12-Pulse with IRM / A1 RFI
[6] Braking and safety (character 18)
X No brake IGBT
B Brake IGBT
Safe Torque Off with Pilz Safety Relay
C
(enclosure sizes F1, F2, F3, F4)
Safe Torque Off with Pilz Safety Relay
D and brake IGBT
(enclosure sizes F1, F2, F3, F4)
Safe Torque Off with Pilz Safety Relay and
E regeneration terminals
(enclosure sizes F1, F2, F3, F4)
T Safe Torque Off without brake
R Regeneration terminals (enclosure sizes D & F)
S Regeneration terminals and brake chopper
U Brake IGBT plus Safe Torque Off
Enclosure sizes F3, F4
IEC Emergency Stop Pushbutton
M
(includes Pilz Relay)
IEC Emergency Stop Pushbutton with brake
N IGBT and brake terminals
(includes Pilz Safety Relay)
IEC Emergency Stop Pushbutton with
P regeneration terminals
(includes Pilz Safety Relay)
[7] LCP display (character 19)
X Blank faceplate, no LCP installed
N Numerical Local Control Panel (LCP 101)
G Graphical Local Control Panel (LCP 102)
Enclosure size D and E, IP21/IP54 only
J No Local Control Panel + USB through door
Graphical Local Control Panel (LCP 102)
L
+ USB through door
Numerical Local Control Panel (LCP 101)
K
+ USB through door
[17] [18] [19]
– XX –
