Danfoss VLT AutomationDrive FC 300 Series Selection Manual page 48

VLT® Relay Card MCB 105
Makes it possible to extend relay functions with
3 additional relay outputs.
„
Max. switch rate at rated
load/min. load ............................... 6 min
„ Protects control cable connection
„
Spring-loaded control wire connection
Max. terminal load:
„ AC-1 Resistive load ........................... 240 V AC 2 A
„ AC-15 Inductive
load @cos phi 0.4 ...........................240 V AC 0.2 A
„ DC-1 Resistive load ..............................24 V DC 1 A
„
DC-13 Inductive
load @cos phi 0.4 ............................. 24 V DC 0.1 A
Min. terminal load:
„ DC 5 V .......................................................................10 mA
Ordering number
130B1110 standard
130B1210 coated (Class 3C3/IEC 60721-3-3)
VLT® Safe PLC I/O MCB 108
The VLT® AutomationDrive FC 302 provides a
safety input based on a single-pole 24 V DC
input.
„ For the majority of applications, this input
enables the user to implement safety in a
cost-effective way. For applications that
work with more advanced products like
Safety PLC and light curtains, the Safe PLC
interface enables the connection of a two-
wire safety link
„ The Safe PLC Interface allows the Safe PLC
to interrupt on the plus or the minus link
without interfering the sense signal of the
Safe PLC
Ordering number
130B1120 standard
130B1220 coated (Class 3C3/IEC 60721-3-3)
VLT® Analog I/O Option
MCB 109
This analog input/output option is easily fitted
in the AC drive for upgrading to advanced
performance and control using the additional
I/O. This option also upgrades the AC drive with
a battery back-up supply for the AC drive built-
in clock. This provides stable use of all AC drive
clock functions as timed actions.
„
3 analog inputs, each configurable as both
voltage and temperature input
„ Connection of 0-10 V analog signals as well
as Pt1000 and Ni1000 temperature inputs
„ 3 analog outputs each configurable as 0-10
V outputs
„ Back-up supply for the standard clock func-
tion in the AC drive
The back-up battery typically lasts for 10 years,
depending on environment.
Ordering number
130B1143 standard
130B1243 coated (Class 3C3/IEC 60721-3-3)
48
Danfoss Drives · DKDD.PB.302.A8.02 | Content |
VLT® PTC Thermistor Card
MCB 112
The VLT® PTC Thermistor Card
MCB 112 enables improved surveillance of the
motor condition compared to the built-in ETR
/20 sec
-1 -1
function and thermistor terminal.
„ Protects the motor from overheating
„
ATEX-approved for use with Ex d and
Ex e motors
„ Uses Safe Torque Off function, which is
approved in accordance with SIL 2 IEC 61508
Ordering number
130B1137 coated (Class 3C3/IEC 60721-3-3)
VLT® Sensor Input Card
MCB 114
This option protects the motor from being
overheated by monitoring the temperature of
bearings and windings in the motor.
„ Protects the motor from overheating
„
3 self-detecting sensor inputs for 2 or 3 wire
PT100/PT1000 sensors
„ 1 additional analog input 4-20 mA
Ordering number
130B1172 standard
130B1272 coated (Class 3C3/IEC 60721-3-3)
VLT® Safety Option
MCB 150 and MCB 151
The VLT ® Safety Options MCB 150 and
MCB 151 expand the Safe Torque Off (STO)
function, which is integrated in a standard
VLT® AutomationDrive. Use the Safe Stop 1
(SS1) function to perform a controlled stop
before removing torque. Use the Safely- Limited
Speed SLS function to monitor whether a
specified speed is exceeded.
The functions can be used up to PL d accord-
ing to ISO 13849-1 and SIL 2 according to
IEC 61508.
„ Additional standards-compliant safety
functions
„ Replacement of external safety equipment
„ Reduced space requirements
„ 2 safe programmable inputs
„
1 safe output (for T37)
„ Easier machine certification
„ Drive can be powered continuously
„
Safe LCP Copy
„ Dynamic commissioning report
„ TTL (MCB 150) or HTL (MCB 151) encoder as
speed feedback
Ordering number
130B3280 MCB 150, 130B3290 MCB 151
VLT® Safety Option MCB 152
The VLT® Safety Option MCB 152 enables activa-
tion of Safe Torque Off (STO) via the PROFIsafe
fieldbus in combination with VLT® PROFINET
MCA 120 fieldbus option. It improves flexibility
by connecting safety devices within a plant.
The safety functions of the MCB 152 are
implemented according to EN IEC 61800-5-2.
The MCB 152 supports PROFIsafe functionality
to activate integrated safety functions of the
VLT® AutomationDrive from any PROFIsafe host,
up to Safety Integrity Level SIL 2 according
to EN IEC 61508 and EN IEC 62061, Perfor-
mance Level PL d, Category 3 according to
EN ISO 13849-1.
„
PROFIsafe device
(in combination with MCA 120)
„ Replacement of external safety equipment
„ 2 safe programmable inputs
„ Safe LCP copy
„ Dynamic commissioning report
Ordering number
130B9860 coated (Class 3C3/IEC 60721-3-3)
