Control

4 Control

4.1 PPO Types

The PROFINET profile for frequency converters specifies a
number of standard telegrams and provides space for
vendor-specific telegrams. The PROFIdrive profile for
4 4
frequency converters is suitable for data exchange
between a process controller (for example PLC) and a
frequency converter. All telegrams are defined for cyclic
data transfer of high-priority data.
Pure process data objects
PPO types 3, 4, 6, 7, and 8 are pure process data objects
for applications requiring no cyclic parameter access. The
PLC sends out process control data, and the frequency
converter then responds with a PPO of the same length,
containing process status data.
Illustration 4.1 shows the available PPO types:
•
PCD 1: The first 2 bytes of the process data area
(PCD 1) comprise a fixed part present in all PPO
types.
•
PCD 2: The next 2 bytes are fixed for PCD write
entries (see parameter 9-15 PCD Write Configu-
ration [1]), but configurable for PCD read entries
(see parameter 9-16 PCD Read Configuration [1]).
•
PCD 3–10: In the remaining bytes, the process
data can be parameterized with process signals,
see parameter 9-23 Parameters for Signals.
Standard telegram
1
Danfoss telegram
PPO 3
PPO 4
PPO 6
PPO 7
PPO 8
Illustration 4.1 Available PPO Types
10
PROFINET
The setting in parameter 9-15 PCD Write Configuration
determines the signals for transmission (request) from the
master to the frequency converter.
The setting in parameter 9-16 PCD Read Configuration
determines the signals for transmission (response) from the
frequency converter to the master.
Select the PPO type in the master configuration. The
selection is automatically recorded in the frequency
converter. No manual setting of PPO types in the
frequency converter is required. Read the current PPO type
in parameter 9-22 Telegram Selection. The setting [1]
Standard telegram 1 is equivalent to PPO type 3.
In addition, all PPO types can be set up as word-consistent
or module-consistent. The process data area can be word-
consistent or module-consistent, whereas the parameter
channel must always be module-consistent.
•
•
CTW/STW REF/MAV
(The old PPO type 3)
CTW/STW REF/MAV
PCD 2 PCD 3
CTW/STW REF/MAV
Read/ Read/
Write Write
PCD 2 PCD 3
CTW/STW REF/MAV Read/ Read/
Write Write
PCD 2 PCD 3
Read/ Read/
CTW/STW REF/MAV
Write Write
PCD 2 PCD 3
CTW/STW REF/MAV Read/ Read/
Write Write
Danfoss A/S © 04/2017 All rights reserved.
Word-consistent data is transmitted as individual,
independent words between the PLC and the
frequency converter.
Module-consistent data is transmitted as sets of
interrelated words transferred simultaneously
between the PLC and the frequency converter.
PCD 4 PCD 5
Read/ Read/
Write
Write
PCD 4 PCD 5 PCD 6 PCD 7
Read/ Read/ Read/
Read/
Write Write Write Write
PCD 7
PCD 4 PCD 5 PCD 6
Read/ Read/ Read/
Read/
Write Write Write
Write
PCD 8 PCD 9
Read/ Read/
Write Write
