6.6 Supported Object and Data Types

6.6.1 Parameter Description
PROFINET has a number of describing attributes.
6.6.2 Size Attribute
The size index and the conversion index for each parameter can be taken from the parameter list in the operating guide for
the frequency converter.
Physical unit
6 6
Time
Energy
Power
Rotation
Torque
Temperature
Voltage
Current
Resistance
Ratio
Relative change
Frequency
Table 6.8 Size Index and Conversion Index
38
PROFINET
Size index Measuring unit
0 No dimension
second
4 millisecond
minute
hour
day
watthour
kilowatthour
8
megawatthour
milliwatt
watt
9
kilowatt
megawatt
11 rotation per minute
newtonmetre
16
kilonewtonmetre
17 degree Celsius
millivolt
21 volt
kilovolt
milliampere
22 ampere
kiloampere
milliohm
23 ohm
kiloohm
24 per cent
27 per cent
hertz
kilohertz
28
megahertz
gigahertz
Danfoss A/S © 04/2017 All rights reserved.
Designation Conversion index
s 0
-1
-2
ms -3
min 70
h 74
d 77
Wh 0
kWh 3
MWh 6
mW -3
W 0
kW 3
MW 6
RPM 67
Nm 0
kNm 3
ºC 0
mV -3
V 0
kV 3
mA -3
A 0
kA 3
mOhm -3
Ohm 0
kOhm 3
% 0
% 0
Hz 0
kHz 3
MHz 6
GHz 9
Conversion factor
1
0.1
0.01
0.001
60
3600
86400
1
1000
6
10
0.001
1
1000
6
10
1
1
1000
1
0.001
1
1000
0.001
1
1000
0.001
1
1000
1
1
1
1000
10 6
9
10
