Troubleshooting
If [2] Logic AND is selected, both signals must be activated
to perform the function.
Terminal Bits 02/03/04
0 0 Stop/Counterclockwise
0 1 Stop/Counterclockwise
1 0 Stop/Counterclockwise
1 1 Start/Clockwise
Table 8.7 [2] Logic AND
If [3] Logic OR is selected, activation of 1 signal activates
the function.
Terminal Bits 02/03/04
0 0 Stop/Counterclockwise
0 1 Start/Clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise
Table 8.8 [3] Logic OR
The effect of control mode on the function of
parameter 8-55 Set-up Select and parameter 8-56 Preset
Reference Select:
If [0] Digital input is selected, the terminals control the set-
up and preset reference functions.
Terminal Bits 00/01, 13/14
Msb Lsb Msb
0 0 0
0 0 0
0 0 1
0 0 1
0 1 0
0 1 0
0 1 1
0 1 1
1 0 0
1 0 0
1 0 1
1 0 1
1 1 0
1 1 0
1 1 1
1 1 1
Table 8.9 [0] Digital Input
MG06G102
Programming Guide
Function
Function
Function
Preset reference set-
Lsb
up number
0 1
1 1
0 1
1 1
0 2
1 2
0 2
1 2
0 3
1 3
0 3
1 3
0 4
1 4
0 4
1 4
Danfoss A/S © 04/2017 All rights reserved.
If [1] Serial communication is selected, commands are
activated only when given via serial communication.
Terminal Bits 00/01, 13/14
Msb Lsb Msb
0 0 0
0 0 0
0 0 1
0 0 1
0 1 0
0 1 0
0 1 1
0 1 1
1 0 0
1 0 0
1 0 1
1 0 1
1 1 0
1 1 0
1 1 1
1 1 1
Table 8.10 [1] Serial Communication
If [2] Logic AND is selected, both signals must be activated
to perform the function.
Terminal Bits 00/01, 13/14
Msb Lsb Msb
0 0 0
0 0 0
0 0 1
0 0 1
0 1 0
0 1 0
0 1 1
0 1 1
1 0 0
1 0 0
1 0 1
1 0 1
1 1 0
1 1 0
1 1 1
1 1 1
Table 8.11 [2] Logic AND
Function
Preset reference set-
Lsb
up number
0 1
1 2
0 3
1 4
0 1
1 2
0 3
1 4
0 1
1 2
0 3
1 4
0 1
1 2
0 3
1 4
Function
Preset reference set-
Lsb
up number
0 1
1 1
0 1
1 1
0 1
1 2
0 1
1 2
0 1
1 1
0 3
1 3
0 1
1 2
0 3
1 4
