4.4 PROFIdrive Control Profile

This section describes the functionality of the control word
and status word in the PROFIdrive profile.
4.4.1 Control Word According to
PROFIdrive Profile (CTW)
4 4
The control word is used to send commands from a master
(for example a PC) to a slave.
Bit
00 OFF 1
01 OFF 2
02 OFF 3
03 Coasting
04 Quick stop
05 Hold frequency output
06 Ramp stop
07 No function
08 Jog 1 OFF
09 Jog 2 OFF
10 Data invalid
11 No function
12 No function
13 Parameter set-up
14 No function
15 Forward
Table 4.8 Control Word Bits
Explanation of the control bits
Bit 00, OFF 1/ON 1
Normal ramp stops using the ramp times of the actual
selected ramp.
Bit 00 = 0 stops and activates the output relay 1 or 2 if the
output frequency is 0 Hz, and if [31] Relay 123 is selected
in parameter 5-40 Function Relay.
When bit 0 = 1, the frequency converter is in state 1,
switching on inhibited.
Refer to Illustration 4.4.
Bit 01, OFF 2/ON 2
Coast stop.
Bit 01 = 0 coast stops and activates the output relay 1 or 2
if the output frequency is 0 Hz, and if [31] Relay 123 is
selected in parameter 5-40 Function Relay.
When bit 01 = 1, the frequency converter is in state 1,
switching on inhibited. Refer to Illustration 4.4.
Bit 02, OFF 3/ON 3
Quick stop using the ramp time of parameter 3-81 Quick
Stop Ramp Time.
Bit 02 = 0 quick stops and activates the output relay 1 or 2
if the output frequency is 0 Hz, and if [31] Relay 123 is
selected in parameter 5-40 Function Relay.
When bit 02 = 1, the frequency converter is in state 1,
switching on inhibited.
14
PROFINET
Bit = 0 Bit = 1
ON 1
ON 2
ON 3
No coasting
Ramp
Use ramp
Start
Reset
Jog 1 ON
Jog 2 ON
Data valid
Slow down
Catch up
Selection lsb
No function
Reverse
Danfoss A/S © 04/2017 All rights reserved.
Refer to Illustration 4.4.
Bit 03, coasting/no coasting
Bit 03 = 0 leads to a coast stop.
When bit 03 = 1, if the other start conditions are fulfilled,
the frequency converter can start.
NOTICE
The selection in parameter 8-50 Coasting Select
determines how bit 03 is linked with the corresponding
function of the digital inputs.
Bit 04, quick stop/ramp
Quick stop using the ramp time of parameter 3-81 Quick
Stop Ramp Time.
When bit 04 = 0, a quick stop occurs.
When bit 04 = 1, if the other start conditions are fulfilled,
the frequency converter can start.
NOTICE
The selection in parameter 8-51 Quick Stop Select
determines how bit 04 is linked with the corresponding
function of the digital inputs.
Bit 05, hold frequency output/use ramp
When bit 05 = 0, the present output frequency is
maintained, even if the reference value is modified.
When bit 05 = 1, the frequency converter can perform its
regulating function again according to the respective
reference value.
Bit 06, ramp stop/start
Normal ramp stop using the ramp times of the actual
ramp selected. In addition, if [31] Relay 123 is selected in
parameter 5-40 Function Relay, and if the output frequency
is 0 Hz, this bit activates output relay 01 or 04.
Bit 06 = 0 stops the frequency converter.
When bit 06 = 1, if the other start conditions are fulfilled,
the frequency converter can start.
NOTICE
The selection in parameter 8-53 Start Select determines
how bit 06 is linked with the corresponding function of
the digital inputs.
Bit 07, no function/reset
Reset after switching off. Acknowledges event in fault
buffer.
When bit 07 = 0, no reset occurs.
When there is a slope change of bit 07 to 1, a reset occurs
after switching off.
Bit 08, jog 1 OFF/ON
Activation of the pre-programmed speed in
parameter 8-90 Bus Jog 1 Speed. Jog 1 is only possible if bit
04 = 0 and bits 00–03 = 1.
Bit 09, jog 2 OFF/ON
Activation of the pre-programmed speed in
parameter 8-91 Bus Jog 2 Speed. Jog 2 is only possible if bit
04 = 0 and bits 00–03 = 1.
