Parameters

6 Parameters
6.1 Parameter Group 0-** Operation/
Display
0-37 Display Text 1
Range: Function:
0 [0 - In this parameter, it is possible to write an individual
*
25 ] text string to be shown in the LCP or to be read via
serial communication.
To show the text permanently, select [37] Display Text
1 in 1 of the following parameters:
6 6
Changing parameter 12-08 Host Name changes
parameter 0-37 Display Text 1 - but not the opposite
way.
6.2 Parameter Group 8-** Communication
and Option
6.2.1 8-0* General Settings
8-01 Control Site
The setting in this parameter overrides the settings in
parameter 8-50 Coasting Select to parameter 8-56 Preset Reference
Select.
Option:
[0] Digital and ctrl.word
[1] Digital only
[2] Controlword only
8-02 Control Source
Option:
[0] None
[1] FC Port
[3] Option A
26
•
Parameter 0-20 Display Line 1.1 Small.
•
Parameter 0-21 Display Line 1.2 Small.
•
Parameter 0-22 Display Line 1.3 Small.
•
Parameter 0-23 Display Line 2 Large.
•
Parameter 0-24 Display Line 3 Large.
•
Parameter 0-37 Display Text 1.
Function:
Use both digital input and
control word.
Use digital inputs only.
Use control word only.
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
Select the source of the control.
Danfoss A/S © 04/2017 All rights reserved.
PROFINET
8-03 Control Timeout Time
Range:
1 s [0.5 -
*
6000 s]
8-04 Control Timeout Function
Select the timeout function. The timeout function activates when
the control word fails to be updated within the time period
specified in parameter 8-03 Control Word Timeout Time.
Option:
[0] Off
*
[1] Freeze output Freeze output frequency until communi-
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip Stop the motor and trip, then reset the
8-07 Diagnosis Trigger
Option:
[0] Disable
*
[1] Trigger on
alarms
[2] Trigger
alarm/warn.
Function:
Enter the maximum time expected to pass
between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the telegram communication has stopped.
The function selected in parameter 8-04 Control
Word Timeout Function is then carried out. A valid
control word triggers the timeout counter.
Function:
Resume control via fieldbus (fieldbus or
standard), using the most recent control
word.
cation resumes.
Stop with auto restart until communication
resumes.
Run the motor at jog frequency until
communication resumes.
Run the motor at maximum frequency until
communication resumes.
frequency converter to restart:
•
Via the fieldbus.
•
Via [Reset].
•
Via a digital input.
Function:
Enable and control the frequency converter
diagnosis function.
Extended diagnosis data is not sent even if
the data appears in the frequency converter.
Extended diagnosis data is sent when 1 or
more alarms appear.
Extended diagnosis data is sent if 1 or more
alarms/warnings appear.
