Danfoss VLT AutomationDrive FC 360 Programming Manual page 31

Parameters
9-22 Telegram Selection
Option: Function:
[100] None
*
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
9-23 Parameters for Signals
Array [1000]
Read only
Option:
[0] None
*
[302] Minimum Reference
[303] Maximum Reference
[311] Jog Speed [Hz]
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[412] Motor Speed Low Limit [Hz]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[553] Term. 29 High Ref./Feedb. Value
[558] Term. 33 High Ref./Feedb. Value
[590] Digital & Relay Bus Control
[593] Pulse Out 27 Bus Control
[595] Pulse Out 29 Bus Control
[615] Terminal 53 High Ref./Feedb. Value
[625] Terminal 54 High Ref./Feedb. Value
[676] Terminal 45 Output Bus Control
[696] Terminal 42 Output Bus Control
[733] Process PID Proportional Gain
[734] Process PID Integral Time
[735] Process PID Differentiation Time
[748] PCD Feed Forward
[890] Bus Jog 1 Speed
MG06G102
Programming Guide
9-23 Parameters for Signals
Array [1000]
Read only
Option:
[891]
[1500] Operating hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference [%]
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
Function:
[1611] Power [hp]
This parameter
[1612] Motor Voltage
contains a list of
[1613] Frequency
signals available for
[1614] Motor current
selection in
[1615] Frequency [%]
parameter 9-15 PCD
[1616] Torque [Nm]
Write Configuration
[1617] Speed [RPM]
and
[1618] Motor Thermal
parameter 9-16 PCD
[1622] Torque [%]
Read Configuration.
[1630] DC Link Voltage
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
[1652] Feedback[Unit]
[1653] Digi Pot Reference
[1657] Feedback [RPM]
[1660] Digital Input
[1661] Terminal 53 Setting
[1662] Analog input 53
[1663] Terminal 54 Setting
[1664] Analog input 54
[1665] Analog output 42 [mA]
[1667] Pulse input 29 [Hz]
[1668] Pulse input 33 [Hz]
[1669] Pulse output 27 [Hz]
[1670] Pulse output 29 [Hz]
[1671] Relay output
[1672] Counter A
[1673] Counter B
[1679] Analog output 45 [mA]
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
Danfoss A/S © 04/2017 All rights reserved.
Bus Jog 2 Speed
Function:
6
29
6
