Parameters
parameter 12-05 Lease Expires. If lease time is set to 0
(zero), the timer never expires.
Parameter 12-09 Physical Address reads out the MAC
address of the option, which is also printed on the label of
the option.
Parameter 12-03 Default Gateway is optional and only used
in routed networks.
NOTICE
It is only possible to assign valid class A, B, and C IP
addresses to the option. The valid ranges are shown in
Table 6.4.
Class A 1.0.0.1-126.255.255.254
Class B 128.1.0.1-191.255.255.254
Class C 192.0.1.1-223.255.254.254
Table 6.4 Valid Ranges for IP Address to the Option
6.5.2 Ethernet Link Parameters
Parameter group 12-1* Ethernet Link parameters:
•
Parameter 12-10 Link Status.
•
Parameter 12-11 Link Duration.
•
Parameter 12-12 Auto Negotiation.
•
Parameter 12-13 Link Speed.
•
Parameter 12-14 Link Duplex.
Each port has unique Ethernet Link parameters.
Parameter 12-10 Link Status and parameter 12-11 Link
Duration show information on the link status, per port.
Parameter 12-10 Link Status shows Link or No Link
according to the status of the present port.
Parameter 12-11 Link Duration shows the duration of the
link on the present port. If the link is lost, the counter is
reset.
Parameter 12-12 Auto Negotiation enables 2 connected
Ethernet devices to select common transmission
parameters, such as speed and duplex mode. In this
process, the connected devices first share their capabilities
and then select the fastest transmission mode they both
support.
Incapability between the connected devices could lead to
decreased communication performance.
To prevent this, auto negotiation can be disabled.
If parameter 12-12 Auto Negotiation is set to OFF, link speed
and duplex mode can be configured manually in
parameter 12-13 Link Speed and parameter 12-12 Auto
Negotiation.
MG06G102
Programming Guide
Parameter 12-13 Link Speed shows/sets the link speed for
each port. If no link is present, none is shown.
Parameter 12-14 Link Duplex shows/sets the duplex mode
for each port.
6.5.3 Introduction
Changes during operation
True means that the parameter can be changed while the
frequency converter is in operation. False means that the
frequency converter must be stopped before a change can
be made.
2 set-up
All set-ups: The parameter can be set individually in each
of the 2 set-ups, for example, 1 single parameter can have
2 different data values.
1 set-up: The data value is same in all set-ups.
Data
type
2
3
4
5
6
7
9
33
35
54
Table 6.5 Data Type
Danfoss A/S © 04/2017 All rights reserved.
Description
Integer 8
Integer 16
Integer 32
Unsigned 8
Unsigned 16
Unsigned 32
Visible string
Normalized value 2 bytes
Bit sequence of 16 boolean variables
Time difference w/o date
6 6
Type
Int8
Int16
Int32
Uint8
Uint16
Uint32
VisStr
N2
V2
TimD
